Improve electrical use to reduce power consumption, boost reliability and provide higher data-write performance.
DRAM Cache Buffer
TEAMGROUP L5 3D SSD comes with DRAM Cache Buffer which is able to enhance the speed and performance of the overall system.
Smooth R/W Speed
The speed of 1TB is up to 500MB/s which not only allows fast boot/shutdown time but also speeds up the response time of all applications.
The L5 3D SSD has an industry-standard 2.5-inch size. Whether it is for laptop or desktop, the upgrade can be done easily and quickly.
Release free blocks, allowing an operating system to use them later immediately when writing data.
Monitor SSD status efficiently. Detect and repair sector errors to prevent failure.
Solid, Durable, Total Protection
The L5 3D SSD uses 3D NAND flash memory chip, which is durable, shockproof, drop resistant and offers a total protection for the data. Even if you accidentally drop your computer or it landed on a hard surface, it can still prevent damage and data corruption from accidents.
|Interface||SATA Rev. 3.0(6Gb/s) - with backwards compatibility to SATA Rev. 2.0|
|Capacity||120GB / 240GB / 480GB / 1TB|
|Operation Temperature||0°C ~ 70°C|
|Storage Temperature||-40°C ~ 85°C|
|Performance||ATTO / Crystal Disk Mark:
120GB Read: 470MB/s; Write: 300MB/s
240GB Read: 470MB/s; Write: 400MB/s
480GB Read: 470MB/s; Write: 420MB/s
1TB Read: 500MB/s; Write: 480MB/s
120GB 4K Random Read/Write: 30K/40K IOPS max
240GB 4K Random Read/Write: 65K/70K IOPS max
480GB 4K Random Read/Write: 70K/70K IOPS max
1TB 4K Random Read/Write: 80K/70K IOPS max
|Dimensions||100(L) x 69.9(W) x 7(H)mm|
|Humidity||0°C to 55°C / 5% ~ 95% RH, non-condensing|
|Operating System||Desktop or notebook computer with a SATA III interface Windows 10 / 8 / 7 / Vista, MAC OS 10.4 or later, Linux 2.6.33 or later|
|Warranty||3-year limited warranty|
 1GB=1,000,000,000 Bytes. In OS system, it would be displayed as 1,000.000,000 Bytes/1024/1024/1024= 0.93GB
 Definition and conditions of TBW (Terabytes WrittenJare based on JEDEC standard
 Transmission speed will vary according to different hardware/software conditions, therefore the data can only use for basic reference.
 PCIe SSD works best under WIN8.1 and WIN 10 operating system. Windows Operating Systems earlier than Windows 8.1 does not support NVMe Driver natively. Users will need to install NVMe Driver prior installing the SSD.
