Thermaltake Silent Purepower W0010 480 W ATX Active PFC Power Supply
- ATX
- 100 - 240 V 50/60 Hz
- +3.3V@30A; +5V@40A; [email protected]; +12V@18A; [email protected]; +5VSB@2A
Specs
Reviews (44)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Thermaltake W0010
| Brand | Thermaltake |
|---|---|
| Series | Silent Purepower |
| Model | W0010 |
| Type | ATX |
|---|---|
| Maximum Power | 480 W |
| Fans | 1 x 80mm, Two Ball Bearing Temp. Auto Control 2 x 80mm, Ball Bearing, 2400rpm |
| PFC | Active |
| Main Connector | 20Pin |
| +12V Rails | Single |
| SLI | No |
| Modular | No |
| Power Good Signal | 100-500ms |
| Hold-up Time | 16ms min. |
| Efficiency | > 65% |
| Over Voltage Protection | +5V trip point < +6.8V +3.3V trip point < +4.5V +12V trip point <+15.6V |
| Input Voltage | 100 - 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 8A |
| Output | +3.3V@30A; +5V@40A; [email protected]; +12V@18A; [email protected]; +5VSB@2A |
| Connectors | 1 x Main connector (20 pin) 1 x 12V (P4) 9 x peripheral 2 x SATA 2 x Floppy |
| Features | Temperature Automatic Fan Speed Control |
|---|
| First Listed on Newegg | June 02, 2003 |
|---|
