Specifications | Doorbell Image Sensor: 1/2.8" Resolution: 3 MP HD (2304 x 1296 pixels) Night Vison: 850 nm IR LED up to 15 ft. Lens: F/NO: 2.1; Focal Length: 2.1 mm Viewing Angle: Diagonal FOV = 160° Storage: Supports Micro SD card, up to 128 GB (microSD card not included.)
Audio Doorbell Audio Communication: 2-way audio Doorbell Audio Input & Output: Built-in microphone and speaker Chime Audio Output: 8 Ringtones and Built-in speaker
Video Video Compression: H.264 Frame Rate: 15 fps Video Streaming: 3 MP HD (2304 x 1296 pixels) Audio Compression: G.711
Network Wireless Rate: 11Mbps (802.11b) 54Mbps (802.11g) 72.2Mbps (802.11n) Frequency: 2.4 GHz Wireless Security: WEP, WPA/WPA2-PSK Security: 128 bit AES encryption with SSL/TLS
Requirements Existing Doorbell Wires: Yes Transformer (not Included): 16V AC ~ 24V AC, 10 VA Minimum, 50/60Hz
Environment Operating Temperature: -20°C~45°C (-4°F~113°F) Storage Temperature: -20°C~70°C (-4°F~158°F) Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing |
---|
