T2500-28TC
JetStream 24-Port 10/100Mbps + 4-Port Gigabit L2 Managed Switch
Expand and upgrade your network with the T2500-28TC managed switch. It provides full set of layer 2 management features and delivers maximum throughput where you need it. Robust security protects the device against broadcast storm, ARP and Denial-of-Service (DoS) attacks, etc.
Secure Networking
TP-LINK JetStream L2 managed switch T2500-28TC provides IP-MAC-Port Binding, Port Security, Storm control and DHCP Snooping which protect against broadcast storms, ARP attacks, etc. It integrates some typical DoS attacks to select. You can protect it from these attacks more easily ever than before. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports and even VLAN ID. Moreover, the switch supports 802.1X authentication, which is used in conjunction with a RADIUS server to require some authentication information before access to the network is allowed. Guest VLAN function supports to enable the non-802.1X clients to access the specific network resource.
Non-Blocking Switching
TP-LINK JetStream L2 managed switch T2500-28TC provides non-blocking switching solution for a 10/100Mbps fast Ethernet connection. As to the switching capacity, T2500-28TC has a non-blocking aggregated bandwidth of 12.8Gbps. It provides 24 10/100Mbps ports and 4 gigabit 10/100/1000BASE-T ports. All of these ports are combo gigabit ports, which will be disabled if the corresponding 1000BASE-X SFP slots are used. It can give you greater network flexibility.
Ethernet OAM
The T2500-28TC provides 802.3ah OAM and Device Link Detection Protocol (DLDP) functions improving monitor and troubleshooting Ethernet networks to help facilitate network management.
DDM
The T2500-28TC provides DDM (Digital Diagnostic Monitoring) function to view the status of SFP modules inserting into the Switch and to configure alarm settings, warning settings, temperature threshold settings, voltage threshold settings, bias current threshold settings, TX power threshold settings, and Rx power threshold settings.
Optimized Voice and Video Applications
To integrate voice, data and video service on one network, T2500-28TC applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including IP or MAC address, TCP or UDP port number, etc, so voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN the switch supports, the voice applications will operate with much smoother performance.
For other multimedia-on-demand applications such as IPTV, T2500-28TC provides advanced features for easy stream management. For example, IGMP snooping ensures the switch intelligently forwards the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restricts each subscriber on a port level to prevent unauthorized multicast access.
Enterprise Level Management Features
T2500-28TC is easy to use and manage. It supports various user-friendly standard management features, such as intuitive web-based Graphical User Interface (GUI) or industry-standard Command Line Interface (CLI), administration traffic can be either protected through SSL or SSH encryptions. SNMP (v1/v2c/v3) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events.
