tp-link tl-sg1008d 8-port unmanaged gigabit switch
- TP-Link 8 Port Gigabit Switch (TL-SG1008D)
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Specifications Mfr
Part Number:
TL-SG1008DFeatures: Supports IEEE 802.3 x flow control for Full Duplex mode and backpressure for Half Duplex mode Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput Supports MAC address auto-learning and auto-aging LED indicators for monitoring power, link, activity Plastic case, desktop or wall-mounting design External power adapter supply
Standards and Protocols: IEEE 802.3, 802.3 u, 802.3 ab, 802.3 x, CSMA/CD, TCP/IP
Ports: 8x 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto
MDI/MDIX) Basic Function: Wire-speed Performance MAC Address Auto-Learning and Auto-aging IEEE 802.3 x flow control for Full-Duplex Mode and backpressure for
Half-Duplex Mode Backbound Bandwidth: 16Gbps
MAC Address Table: 4k
Forwarding Rate:
10BASE-T: 14880pps/port
100BASE-TX:
148800pps/port1000BASE-T: 1488000pps/port
Transmission Method: Store-and-Forward
Network Media:
10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100?
STP (maximum 100m) 100Base-Tx: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100?
STP (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED Indicator: Power, 10/100M, 1000M
Safety & Emission: FCC, CE
Power: External Power Adapter Dimensions (WxDxH) 7.9 x 5.5 x 1.1 inch / 200.0 x 140.0 x 28.0 mm
Part Number:
TL-SG1008DFeatures: Supports IEEE 802.3 x flow control for Full Duplex mode and backpressure for Half Duplex mode Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput Supports MAC address auto-learning and auto-aging LED indicators for monitoring power, link, activity Plastic case, desktop or wall-mounting design External power adapter supply
Standards and Protocols: IEEE 802.3, 802.3 u, 802.3 ab, 802.3 x, CSMA/CD, TCP/IP
Ports: 8x 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto
MDI/MDIX) Basic Function: Wire-speed Performance MAC Address Auto-Learning and Auto-aging IEEE 802.3 x flow control for Full-Duplex Mode and backpressure for
Half-Duplex Mode Backbound Bandwidth: 16Gbps
MAC Address Table: 4k
Forwarding Rate:
10BASE-T: 14880pps/port
100BASE-TX:
148800pps/port1000BASE-T: 1488000pps/port
Transmission Method: Store-and-Forward
Network Media:
10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100?
STP (maximum 100m) 100Base-Tx: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100?
STP (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED Indicator: Power, 10/100M, 1000M
Safety & Emission: FCC, CE
Power: External Power Adapter Dimensions (WxDxH) 7.9 x 5.5 x 1.1 inch / 200.0 x 140.0 x 28.0 mm
