Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
Jumbo Frames
9216 bytes
Details
Security
SSH v1/v2 SSL v2/v3/TLSv1 Port Security Broadcast/Multicast/Unknown unicast Storm Control
SNMP
SNMP v1/v2c/v3, compatible with public MIBs and
QoS
Support 802.1p CoS/DSCP priority Support 4 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting Voice VLAN
LACP
Yes
Layer
L2 Features IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 6 aggregation groups, containing 4 ports per group) Spanning Tree STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loop back detection 802.3x Flow Control
Port Mirroring
Yes
Power
100~240VAC, 50/60Hz
Features
Features
Gigabit Ethernet connections on all ports provide full speed of data transferring
Integrated security strategy including 802.1Q VLAN, ACL, Port Security and Storm control help protect LAN area investment
L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
WEB/CLI managed modes, SNMP, RMON bring abundant management features
Innovative energy-efficient technology saves up to 65% of power consumption
