• SSI CEB form factor and optional dual port Intel X550 10GBase-T Ethernet.
• Intel Ice Lake SP Xeon Processor with TDP up to 270W
• Chipset
• Intel C621A PCH
• Memory
• (8) DDR4 DIMM slots (8 memory channels)
• Supporting up to 2TB RDIMM/LRDIMM DDR4-3200
• PCIe Expansion Slots
• Slot 1: PCIe Gen 4.0 x0 or x8 (MUX with Slot 2)
• Slot 2: PCIe Gen 4.0 x16 or x8 (MUX with Slot 1)
• Slot 3: PCIe Gen 4.0 x4
• Slot 4: PCIe Gen 4.0 x16
• Slot 5: PCIe Gen 4.0 x16
• Network
• (2) 10GBase-T LAN Ports (Intel X550-AT2) (Optional)
• (1) 1000Base-T LAN Port (Intel i210)
• (1) 1000Base-T Dedicated IPMI Port (Realtek TRL8211 PHY)
• Storage
• (14) SATA 6G w/ Intel RSTe 5.0 RAID support
• (2) PCIe Gen 4.0 NVMe ports across one PCIe x8 Slimline connector
• (2) 2280/22110 PCIe Gen 3.0 x2 NVMe M.2 ports (from PCH)
• Optional TPM 1.2 & 2.0 modules
• AST2500 BMC /w IPMI, iKVM, and Redfish Support
