Best Seller Ranking | #25 in Wireless AP |
---|
Brand | Ubiquiti Networks |
---|---|
Series | WIFI Access points |
Model | AC Mesh |
Part Number | UAP-AC-M |
# of Users | 200+ |
---|---|
Standards | 802.11a/b/g/n/ac |
WiFi Generation | Wi-Fi 5 |
Wireless Data Rates | 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) |
Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
Antenna | 2.4 GHz 2 x 2 (DL MU-MIMO) 5 GHz 2 x 2 (DL MU-MIMO) |
Transmitted Power | 2.4 GHz 20 dBm 5 GHz 20 dBm |
Mounting Location | Indoor / Outdoor |
Operating Range | Indoor: Up to 140m, Outdoor: Up to 140m |
Interface | (1) GbE RJ45 port |
LAN Ports | (1) GbE RJ45 port |
Power Supply | Gigabit PoE adapter 24V, 0.5A* |
Temperature | -30 to 70° C (-22 to 158° F) |
---|---|
Humidity | 5 to 95% noncondensing |
Dimensions | 353 x 46 x 34.4 mm (13.9 x 1.8 x 1.4") |
---|---|
Weight | 152 g (5.4 oz) |
Features | VLAN 802.1Q BSSID Up to 4 per radio Advanced QoS Per-user rate limiting Guest traffic isolation Supported Power save Supported WMM Voice, video, best effort, and background Concurrent clients 250+ |
---|
Date First Available | October 03, 2023 |
---|
