Vivotek CU9183-HF, VC9101 Unit, Flat Shape (Fisheye)

Be the first to review this product...
  • 5MP Resolution @ 30fps
  • 360 Degree Fisheye Lens, Local Dewarp
  • WDR Pro for Unparalleled Visibility
  • Supreme Night Visibility for Low Light Scene
  • Discreet, Recessed
This item is covered under the Manufacturer Only Return Policy.
Specs
Reviews
See all Q & A
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the VIVOTEK Inc. CU9183-HF

Model
Brand Vivotek
Series S Series
Model CU9183-HF
Part Number CU9183-HF
Details
Network Camera Yes
Type Fisheye Camera
Color Black
Camera
Sensor & Detector CMOS
MAX Resolution 1920 x 1920
Frame Rate H.265/H.264/MJPEG:
30 fps @ 1920x1920 (WDR On)
Lens Type Fixed Focal Lens
Shutter Control Shutter Time: 1/5 sec. to 1/32,000 sec.
Night Vision Yes
Power
Power Power Input: sensor unit USB micro b (female); cable USB mirco b (male) <=> RJ11
Power Consumption: < 1.25W
Working Environment
Humidity Humidity

Outdoor series 98% RH (non-condensing)
Indoor series 90% RH (non-condensing)
Temperature Operating Temperature

Starting Temperature:
0°C ~ 50°C (32°F ~ 122°F)
Working Temperature:
-10°C ~ 50°C (14°F ~ 122°F)
Dimension & Weight
Dimension 33x32x28 mm (without cable)
Weight 5m cable: < 210g
Camera: 52g
Features
Features VIDEO

Maximum Streams: 3 video streams (Up to 8 configurable profiles)
Main Stream: 30 fps @ 1920x1920
2nd Stream: 30 fps @ 1920x1920
3rd Stream: 30 fps @ 1280x1280

S/N Ratio: 56.3 dB
Dynamic Range: 120dB

Video Streaming: Adjustable resolution, quality and constrained bit rate control, Smart Stream III

Image Settings
General settings: video title and time stamp overlay, video orientation (flip, mirror)
Image settings: white balance, image adjustment (brightness, contrast, saturation, sharpness), defog, 3DNR, HLM, scene mode (auto, deblur)
Exposure: BLC, HLC, exposure control (exposure level, exposure time, gain control), AE speed adjustment, WDR
Additional Information
First Listed on Newegg December 02, 2025

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 2 years
  • Limited Warranty period (labor): 2 years
