Walkera Ready to Fly Quadcopter with DEVO F12 Remote (Integrated LCD Monitor), iLook+ (1080P) camera QR X800 RTF3
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Walkera QR X800 RTF3
| Brand | Walkera |
|---|---|
| Model | QR X800 RTF3 |
| Specification | QR X800 Type: 800 size Quadcopter Main control board: FCS800 Servo: WK-4005 Main rotor dia.: 1200mm Main rotor length: 400mm Brushless motor: WK-WS-48-001 Brushless ESC: WK-WST-60A-6 Battery: 6S 22.2V 6000-lOOOOmAh (not included) Flight time: 30~60mins (depends on loading weight) Flying weight: 3900g (with 6S lOOOOmAh 10C Walkera battery - not included) Dimension: 620x620x460mm Aluminum case dimension: 530x235x560mm DEVO F12 Encoder: 12-channel micro computer system control range: > 1000m (2.4G) Image range: > 300m (5.8G) Channel selection: 8 Channels Frequency: 2.4Ghz Output power: ^100mW Current consumption: < 1000mA Battery: 3.7V 3000mAh Li-Po Size:(L*W*H): 200*201 *79mm iLooK+ HD Camera Video Resolution: HD1920*1080P Video frame rate: 30FPS Video Format: MOV Video Compressing Format: H.264 Image pixel: 300 Resolution: 4032*3024 Pixels Video Format: MJPG Standby Power Loss: 1.33W Working Power Loss: 1.9W Supply Voltage: 3.7V ~ 5V Working Temperature: -10 ~ +70° C Lens Spec: 1/3" Lens Angle: 170° (MAX) Weight: 922g (W/O TX battery) Standby time: 10h G-3D Support iLook, iLook+, GoPro series camera video auxiliary output. Support power supply voltage compensation. Support the motor drive end short circuit protection. Support initial tilt and roll angle custom. Support stick position mode and rate mode. Support regular receiver. Operating voltage: DC 7.4V-28V (recommended 12V, 3S lipo battery). Operating current: 500mA-600mA (depends on the voltage supplied and motor power). Operating temperature: -15?> 65?. Sensor: 3-axis MEMS gyro and 3-axis MEMS accelerometer. Control accuracy: 0.02°. Angle control range: -135°-90° (tilt), -45°-45° (roll). Applicable camera: iLook, iLook+, GoPro Series. Size: 114.3mm x 97.5mm x 106.6mm(L x W x H). Weight: 188g(Without camera). The controller program can be upgraded on Walkera website (UP02 and UP02 adapter requested). |
|---|
| Feature | QR X800 Professional level aerial photography GPS quadcopter Ideal for use with Sony RX100, Walkera iLook, Gopro Hero3 or other action cameras Retractable landing legs Foldable "umbrella" frame design for ultimate portability Sony or G-3D brushless camera gimbal ready (different version optional) Incredible 30~45 minute flight time All new FCS800 Multi-Axis control system (APM based) DEVO F12 5.8 GHz FPV real time Image monitor 4.7" color touch screen Telemetry function iLooK+ HD Camera Pixel: 1300 -- HD Physical Pixel Real-time image transmission -- Built-in 5.8G real-time image transmission system Wide-angle lens -- a wider video-shooting range G-3D Simple operation, More stable for shooting video - Smart design, Aluminium production - High precision brushless motor driving control system - Perfect support iLOOK. iLook+, GoPro3, GoPro3+ camera |
|---|
| Package Content | Ready to Fly Quadcopter with DEVO F12 Remote (Integrated LCD Monitor), iLook+ (1080P) camera, G-3D Gimbal and Aluminum Carrying Case |
|---|
| First Listed on Newegg | December 04, 2014 |
|---|
