Wavlink Technology
The new USB Type-C connector works seamlessly with this Ultra HD 4K Universal Docking Station. It can connect to any host with Standard A or Type C connectors providing a fully backward-compatible and future proof docking solution. Allow you to connect up to two additional monitors and eleven accessories through a single USB cable. Including the latest drivers for compatibility with Windows 10, 8.1 and 7 or Apple Mac OS,it features two DisplayPort or HDMI outputs for mirroring/extending your Windows desktop to external monitors, a Gigabit Ethernet port, audio input and output ports, and six USB 3.0 ports.
- Please download the latest driver from displaylink:
www.displaylink.com/downloads
Suggested for web/productivity software. We do not recommend this docking station for gaming.
With broad compatibility and connectivity, DisplayLink can work with any device that has a USB port. Incredibly high quality video content on a 5K monitor from your laptop allows you to scale from huddle rooms to large-scale boardrooms, hassle-free.
Mac macOS High Sierra needs attention:
1, Since macOS High Sierra 10.13, the user has to explicitly enable this system extension in the Security & Privacy system preference after installation and before the DisplayLink software is allowed to run.
2, macOS Catalina 10.15 requires the user to permit "Screen Recording" in order for DisplayLink devices to work properly.
Boost Productivity in your home or work office and add versatility to your PC Laptop Desktop.Quickly turned your laptop into a decent functioning workstation with dual monitors.
65W Host Charging - Advanced Power Delivery(PD) Funtion
Dock provides usb-c power delivery up to 65W maximum of upstream charging to compatible and also power to the others peripherals simultaneously with 100Watt Power Adapter, 40Watt power for all downstream devices(such as cell phone ). You can do anything you want without worrying Low-Power.
Note: Use PD Function, PC computer or laptop must with an available USB PD USB-C Port(Thunderbolt 3 compatible)
Great for Ultra HD tasks that include video and photo editing.Cut down the time it takes to work on those highly productive tasks.Suggested for web/productivity software.
Support dual 4K Display: Dual 3840x2160@60Hz (4K UHD) video outputs through DP + DP, DP + HDMI and HDMI + HDMI.
Single 5K Display: DisplayPort output up to 5120 x 2880@60Hz when using dual DP simultaneously and with single 5K monitor/TV.
Support dual 5K Display: New 10.0 release version support dual DP 5120x1440@60hz for Windows 7, 8.1 and Windows 10 and Windows 10 v1607 and later.
It will greatly help you work on high-resolution works, graphically intensive images, video editing, CAD drawings, medical images and so on.
Does not support DisplayPort MST daisy-chain connections or Dual-Link DVI conversions. Does not support monitors with 1366x768 optimal resolutions.
Vizio M-Series 4K TVs are only compatible at 4K@30Hz. Not compatible with Acer G-Sync enabled monitors' DisplayPort port, like the Acer XB321HK.
RJ45 Gigabit LAN female port definitely provides stable and faster network connection, automatically adapts to 10M/100M/1000Mbps network transmission.
*Not compatible with virtual networks.(like VPN)
Compatible with any devices with standard 3.5mm Audio port, ideal for connecting a wide variety of devices including headphones with and without mic, speakers, mic system and so much more.
Just plug and enjoy premium sound quality with lossless stereo signal transmission .
6 x USB 3.0
USB 3.0 provides up to 5Gbps data transfer speeds, which is 10 times faster than USB 2.0. The item features 6 USB 3.0 ports, allowing for SuperSpeed data transfer between peripherals. ease of use of your laptop including mouse, keyboards, controllers, printers, external GPU and so much more! These ports are also compatible with USB 2.0.
*Bluetooth devices may cause network delays.
Host connection: USB 3.0/3.1 port (Type A or C)
Processor: Intel Core i7 2+GHz / AMD Richland A10-575x / AMD Kaveri A10-7400P or better
Memory: 8GB
Graphics processor: Integrated or discreet Intel HD 4000, ATI Radeon HD 8650, NVidia GeForce 7xxM graphics processors or better
Disk: 7200RPM or SSD
Operating System:
Legacy Windows XP - Vista/ Vista /7 / 8.1 / 10
-Mac OS X 10.8 onwards
-Chrome OS R51 onwards
-Ubuntu 14.10 onwards
Not Compatible With: Windows XP (64-bit ) and Surface RT.(Please refer to Display Link website for more system compatibility)
How to Reach 4K@60hz
Support resolution up to 5K / 4K / 1080p / 1080i / 720p / 480p
HDMI monitors must support HDMI 2.0 and HDMI cables must support High Speed HDMI
DisplayPort equipped monitors and the DisplayPort cable must support DisplayPort 1.2 specification
Not recommended for use DisplayPort 1.1 OR previous HDMI specifications.
New 10.0 version can not support Dual HDMI 5K display,other OS system such as win8 will not support
ANDROID and CHROME
ANDROID: Available on the Google Play Store. For Android v5.0 (Lollipop) or Later
CHROME: DisplayLink USB devices are supported on Chromebooks.
For more information: support.displaylink.com/knowledgebase/articles/891030
Note:
MacOS 10.13.4 no longer supports DisplayLink. Turn off automatic updates to remain on 10.13.3.
Max 5K(5120 x 2880@60Hz) resolution only via dual Display Ports
The 60W written in the package has actually been upgraded to the latest firmware to support MAX 65W charging
Pros: The new stand up design improves stability over previous generation. Easier to use and navigate. Headphone and Mic IO on top make it easy to connect and disconnect headphones. The HDMI and DVI make it easier to connect displays for setups with limited display outputs. Super speed and fully powered USB ports make portable hard drives easily accessible.
Cons: There's no USB ports on the front which might have been helpful. The product needs to be handled carefully otherwise glossy body is prone to scratches. If the power cord is lost, it might be hard to replace with a more generic once since the port is differently sized from most 12V adapters
Overall Review: This new standing up type doc really has me all excited it is much easier to place on the side of my computer and keep everything connected and stable. I like the flexibility of attaching screens that my onboard graphic IO does not support. Its so amazing to have USB ports on the edge of my monitor instead of running usb extensions all the way on my work desk. This helps keep my desk tidy and makes everything more productive
