Question 1

what program do you use to design your creations?

Accepted Answer

I use thingiverse on the internet for a lot of my projects and if you go on youtube and search chuck hellebuyck's electronic products. Chuck does a lot of 3D printing and show you some free programs to use and how to use them.

Question 2

this indicates abs printing but all other websites indicate abs filament and pla filaments. whats the difference with this model 1.0?

Accepted Answer

From what I understand all FFM 3D printers that XYZprinting produces can use both ABS and PLA plastic. The differences between the models are:
1.0 has 1 extruder
2.0 has 2 extruders
1.0 all in one has 1 extruder and a scanner.
This means that the base 1.0 model has the largest print volume, the all in one have slightly less volume and the 2.0 model will allow you to print in 2 colors at the cost of 5cm of width on the print volume.

Question 3

Does this product come shipped with a cartridge of ABS plastic filament or do I have to order some when I purchase this printer?

Accepted Answer

It comes with filament

Question 4

Is the XYZ software still a drawback for the printer? If so is it still possible to use a different firmware? I'm reluctant to purchase because of this single issue.

Accepted Answer

The newer printers cannot be flashed to an older firmware. They changed the model slightly, and modders haven't figured out how to make this version accept a firmware rollback. That said, you can still do some interesting things with this printer as-is. By blocking the XYZ software at the firewall, you can keep it from updating and leading to a potential problem with future versions that has been known to brick your printer if their servers detect a "malformed" serial key on the printer cartridge. You can buy a cartridge resetter kit that allows you to convert a cartridge into a "dummy", and trick the printer into thinking you have a factory cartridge installed. By doing this, and then feeding any spool you want into it, the printer will use any plastic you can buy, and doesn't require a firmware change. Also, there are guides online for how to use slic3r for your GCODE generation, convert it into a 3w file(native format for this printer), and give you full customization of your prints. Without modifying ANY software or firmware, I am able to use slic3r and any plastic I want with this printer.

Question 5

Cubic inches per cartridge?

Accepted Answer

If you are talking about the plastic that us used for printing, they are measured by weight and they are typically .6Kg and 2.2Kg. I used the started plastic (plain white) and it was the smaller .6, it lasted quite a while. I built several small and several large projects before it ran out. From now on I am only purchasing the larger spools since I dont want to run out in the middle of the build.
I hope this helps.

Question 6

I am looking for a printer for cosplay type renders, is this a printer that I can utilize for that? Or would you recommend a different platform? I want to make full sized wearable costumes from what is printed. Thanks in advance.

Accepted Answer

This is a great printer for its price and its build volume. I use my printer for different cosplay events. With this printer you can print 200mmx200mmx200mm. If you are able to print the costumes you need with the build volume, the price can't be beat. The only other printer I would recommend is an ultimaker 2. With an ultimaker you can make larger objects, but it is a lot more expensive.


	da Vinci Jr. 1.0	da Vinci Jr. 1.0w	da Vinci Jr. 1.0 3-in-1	da Vinci 1.0	da Vinci 1.0 Pro	da Vinci 1.0 Pro 3-in-1	da Vinci 2.0 Duo
Printer Weight(lbs)	26.4 lbs	26.4 lbs	33.07 lbs	55 lbs	58.6 lbs	60.63 lbs	60.6 lbs
Shipping Dimensions (ln)	21.53 x 22.87 x 18.7 inch	21.53 x 22.87 x 18.7 inch	21.53 x 22.87 x 18.7 inch	22.1 x 27.6 x 23.3 inch	22.1 x 27.6 x 23.3 inch	22.1 x 23.3 x 27.6 inch	22.1 x 27.6 x 23.3 inch
Filament Material	Jr. PLA Filament	Jr. PLA Filament	Jr. PLA Filament	ABS/PLA Filament	ABS/PLA Filament	ABS/PLA Filament	ABS/PLA Filament
Filament Diameter	1.75 mm	1.75 mm	1.75 mm	1.75 mm	1.75 mm	1.75mm	1.75 mm
Maximum Build Volume	5.9 x 5.9 x 5.9 inches	5.9 x 5.9 x 5.9 inches	5.9 x 5.9 x 5.9 inch	7.8x7.8x7.8 inches	7.8 x 7.8 x 7.8 inches	5.9x7.8x7.8 inches	5.9x7.8x7.8 inches
Layer Thickness(Resolution)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)	Fine 0.1 mm (100 microns) Standard 0.2 mm (200 microns) Speed 0.3 mm (300 microns) Ultra Fast 0.4 mm (400 microns)
Print Head	Single Nozzle	Single Nozzle	Single Nozzle	Single Nozzle	Single Nozzle	Single Nozzle	Dual Nozzle
Nozzle Diameter	0.4 mm	0.4 mm	0.4 mm	0.4 mm	0.4 mm	0.4 mm	0.4 mm
Interface	USB 2.0, SD card(32G MAX)	USB 2.0, SD card(32G MAX), Wifi	USB 2.0, SD card(32G MAX), Wifi	USB 2.0	USB 2.0, Wifi	USB 2.0, Wifi	USB 2.0
Others	Auto-loading Filament	Auto-loading Filament	Laser engraver(Optional)		Auto-loading Filament	Laser engraver(Optional)
					Laser engraver(Optional)
Scan size			1x1 in~ 4.7x4.7 in			1.18 x 1.18”- 5.9 x 5.9”
Scan Accuracy			0.25mm			0.25mm
Turntable payload			≤3 Kg/6.6lbs			≤3 Kg/6.6lbs

Brand	XYZprinting
Series	da Vinci
Model	da Vinci 1.0
Part Number	da Vinci 1.0

Color	White
Number of Extruders	1
Technology	FFF (Fused Filament Fabrication)
Build Material	ABS Filament
Build Size	Maximum: 7.80" x 7.80" x 7.80"
Layer Thickness	100 - 400 microns
Print Jets	Single Jet
Filament Diameter	1.75mm
Jets Diameter	0.40 mm
Cartridges Compatible	Propietary Catridges
Connectivity	USB 2.0
Interface	USB
Operation System Requirements	Windows XP (.Net 4.0 required) and Windows 7 above (for PC) Mac OS X 10.8 above-bit (for Mac) Note: Stardard VGA driver on operating system, or a graphics card doesn't support OpenGL 2.1, may cause unknown error in XYZware.
Minimum Hardware Requirements	Hardware Requirements (for PC / Mac) X86 32 / 64-bit compatible PCs with 4 GB+ DRAM (for PC) X86 64-bit compatible Macs with 4 GB+ DRAM (for Mac)
Software Bundle	XYZWare (Printer Driver): File Types .stl, XYZ Format

Dimensions	20.00" x 18.40" x 22.00"
Weight	51.90 lbs. (Cartridges included)

XYZprinting da Vinci 1.0 3D Printer ~ 8" x 8" x 8" Built Volume (Fully Enclosed Design with Heated Bed - ABS/ PLA/ Flexible Filament)

WHAT'S YOUR COLOR?

Big

Easy

Safe

Thoughtful

Dimensions

Package

Technology

Maximum Build Volume (WxHxD)

Resolution

Print Head

Nozzle Diameter

Filament Diameter

Filament Material

Display

Language

Connectivity

Software (XYZWare)

OS Support

Hardware

Learn more about the XYZprinting da Vinci 1.0
