XDUOO MT-601 6N11/E88CC Tube High-Performance Class-A Headphone Amplifier

1.About Tube + Transistor Hybrid amplifier:


The front tube amplifier and rear transistor combine the advantages of two amplifier circuits to achieve the ideal sound effect and make you immersed in the happy atmosphere of music.


The tube amplifier has its unique tube sound, sweet, soft, warm, and listenable voice, and good musicality and atmosphere; but its high-frequency transient response and resolving power are worse than that of transistor especially when listening to a symphony.


Transistor has the advantages of large dynamics, high speed, strong resolving power, and strong driving force, especially suitable for songs with large dynamics; but itis not soft enough and its high-frequency sound is sharp and dry.


2.Tube Amplifier:


Adopt double 6N11 tube for pre-amp, making voice sweet, and exquisite. Can be replaced 6922, E88CC, and other tubes.


3.Transistor for Class-A amplifier:


Adopt transistors for class A buffer, strong output power can easily drive any kind of earphones.


4.Line Out Can be used as a Pre-amplifier:


It has one line output, through the tube, and controlled by volume. lt can be used as the Preamplifier of all kinds of an audio amplifier or active speaker, and improve the sound quality of audio amplifier or active speaker.


5.Enthusiast Capacitance:


Adopt the special enthusiast Japanese ELNA SILMIC(II) capacitance as the coupling capacitance, have a transparent and sweet sound.


Adopt the special enthusiast Japanese RUBICON capacitance as the main filter capacitance, have smooth and warm sound, and splendid high frequency.


6.Sand blast textured panel has a simple appearance


Sandblast textured panel and hard aluminum alloy shell are slap-up and can resist external interference effectively.


Parameters:


Power Supply: DC24V/2A

Gain: +18dB

Output Power: 200mW(32Ohm)

Size: 12*7.8*4cm

Dynamic Range: 85dBA(32Ohm)

Weight: 0.36kg

Frequency Response: 10HZ~ 60KHz (+0.5dB)

S/N: >100dB

Suitable Headphone Impedance: 16~ 600 Ohm

THD+N:=0.01%(1KHz & 320hm)
