7.2-Channel Rated Output Power (20Hz-20kHz, 2ch driven): 140W x 7 (8ohms, 0.06% THD) Dynamic Power per Channel (8/6/4/2 ohms): 175/220/295/415 W
HDMI 8 In / 2 Out (Ver 1.4a)
SIRIUS Satellite Radio Ready
FM/AM Tuner
Overview
Specs
Reviews (31)
AVENTAGE is a dramatic, inspired step forward in audio/video component design. AVENTAGE brings studio-grade sound and sophisticated video enhancements to the home as a result of unparalleled attention to detail in design, engineering and fabrication. Details that, at first glance, would not seem to affect the quality of sight, sound, and control, when brought together within an AVENTAGE component produce a work of visual and acoustic art.
The RX-A3000 A/V Receiver offers 3D and Audio Return Channel over 8 in/2 out HDMI, CINEMA DSP 3D, HQV video quality, new GUI, new YPAO with Reflected Sound Control, network functions, control via web browser, Zone 4 digital output and Control4® certification.
AVENTAGE is a dramatic, inspired step forward in audio/video component design. AVENTAGE brings studio-grade sound and sophisticated video enhancements to the home as a result of unparalleled attention to detail in design, engineering and fabrication. Details that, at first glance, would not seem to affect the quality of sight, sound, and control, when brought together within an AVENTAGE component produce a work of visual and acoustic art.
The RX-A3000 A/V Receiver offers 3D and Audio Return Channel over 8 in/2 out HDMI, CINEMA DSP 3D, HQV video quality, new GUI, new YPAO with Reflected Sound Control, network functions, control via web browser, Zone 4 digital output and Control4® certification.
3D-Ready A/V Receiver (HDMI v1.4)Featuring eight 1080p-capable HDMI v1.4 inputs, the Yamaha RX-A3000 supports new 3D and Audio Return Channel features added in HDMI v1.4 standard.
HQV Vida Video ProcessorThe IDT HQV Vida processor incorporates Auto HQV and HQV StreamClean technologies to automatically enhance the incoming image and provide powerful clean-up of source video, converting standard-definition sources to HD quality and making HD look even more detailed. The latest IDT HQV technology also features 14-bit internal processing and 12-bit output for deep color processing and 3D gamut conversion for xvYCC processing, resulting in accurate conversion of regular and wide gamut content to the display’s native gamut. In addition, The VHD1900 features six axis color control with independent adjustment of any color’s hue, saturation and intensity.
High Definition SoundWith the integrated Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, DTS-HD Master Audio and DTS NEO:6, enjoy ultra-realistic HD surround sound like it was meant to be.
Network Connectivity and DLNA CertifiedWith built-in network connectivity, the Yamaha RX-A3000 enables playback of MP3, WMA, and WAV music from up to 15 PCs, and lets you access to thousands of radio stations available on the Internet. The receiver can also be used as a client for Yamaha's MusicCAST home music server that seamlessly integrates with the MCX-2000 digital audio server within your local area network. A USB port on the front panel allows you to play music from USB flash drives and portable USB music players. Yamaha Network Receivers even let you stream and play vast music content from DLNA-compliant devices on your home network.
Sirius Satellite & Internet Radio and HD Radio ReadyThe Yamaha RX-A3000 is Sirius Satellite Radio ready so you can enjoy all channels of programming on Sirius including music, sports, news, and various entertainment programming. SIRIUS Internet Radio is available without the use of a radio to current SIRIUS subscribers, or with a monthly subscription fee, delivering more than 80 channels of talk, entertainment, sports and 100% commercial free music in CD-quality sound. With HD Radio, experience crystal-clear, CD-quality sound via existing AM/FM radio bands, and tune to multiple programs at the same dial position.
Cinema DSP DigitalYamaha’s Cinema DSP Digital technology creates richly realized independent sound fields to envelop you in unmatched surround sound with accurate placement, smooth movement, exceptional clarity and richness, and startlingly realistic presence.
Learn more about the Yamaha RX-A3000
Model
Brand
YAMAHA
Series
AVENTAGE
Model
RX-A3000
Details
Type
Receiver
Color
Walnut
Channels
7.2-Channel
Remote Control
Yes
On Screen Display
Yes (Graphical User Interface)
Processing
Power Output
Rated Output Power (20Hz-20kHz, 2ch driven): 140W x 7 (8ohms, 0.06% THD)
Dynamic Power per Channel (8/6/4/2 ohms): 175/220/295/415 W
D/A Converter
192kHz/24-bit Audio D/A Converter
Video Upconversion
Component Upconversion: Yes
HDMI Upscaling: Yes (Analog to HDMI / HDMI to HDMI)
Audio
CINEMA DSP: Yes (HD3)
DSP Programs: 23
Compressed Music Enhancer: Yes
Virtual Presence Speaker: Yes
Dialogue Lift: Yes
SILENT CINEMA / Virtual CINEMA DSP: Yes
Dolby TrueHD: Yes
Dolby Digital Plus: Yes
Dolby Pro Logic IIx: Yes
DTS-HD Master Audio: Yes
Pure Direct: Yes
YPAO multi-point measurement: Yes with RSC (Reflected Sound Control) and Angle measurement
Adaptive DRC (Dynamic Range Control): Yes
Initial Volume & Maximum Volume Setting: Yes
Bi-amp capability: Yes
Audio Delay: Yes (0-250 ms)
A.R.T. Wedge: Yes
Video
HDMI 3D passthrough: Yes
HDMI Audio Return Channel: Yes
Video adjustment: Yes with variable parameters
Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync: Yes
Bluetooth (A2DP) compatibility with optional Yamaha Bluetooth Wireless Audio Receiver YBA-10
iPod Compatibility
Yes (with Optional YDS-11/12 or YID-W10)
RS-232
Yes
IR
Yes
12V Trigger
2
Other Connectors
A/V Inputs (S-Video): 5 (All S-Video)
Power
Standby Consumption
0.3 W (IR only)
Features
Features
Network functions - Access to Internet Radio (MP3/WMA) and music files on PC or DLNA Server (WAV, MP3, WMA, AAC, FLAC 96/24) - Web Browser Control via PC or PDA - Receiver Manager through network connection - DLNA V.1.5 certified
Compatible with Windows 7
HDMI (V.1.4a with 3D and Audio Return Channel)
HDMI CEC functionality
HD Radio with iTunes tagging
YPAO-Reflected Sound Control sound optimization with angle measurement and multi-point measurement - DSP Effect Normalization - Room Acoustic Echo - Controlling reflection and echo
Assignable component video and optical/coaxial (except Video Aux) inputs allow for a wide range of sources
Video Adjustment Preset
Ability to change HDMI input while in Standby Through mode
USB port for portable audio players and flash drives (MTP/MSC)
iPod/iPhone compatibility with optional YDS-12 Universal Dock
iPod song titles displayed in English and Western European languages on the front panel and on-screen display
Wireless connection for iPod/iPhone with optional YID-W10
Auto power down function with variable time setting
HD Audio decoding with CINEMA DSP 3D (17 DSP programs)
Compressed Music Enhancer with CINEMA DSP
CINEMA DSP 3D, expandable to 11.2 channels (with front and rear presence speakers) by adding an external amp
Virtual Presence Speaker function for CINEMA DSP 3D without Front Presence Speakers
Channel expandability with external amplifier (11-channel expandability (bi-amping))
Adaptive DRC (Dynamic Range Control) and Adaptive DSP Level
Dialogue Lift
Zone 2/Zone 3/Zone 4 on/off and control on front panel
Zone GUI (song/station select, album cover art display, zone tone controls/Zone balance, short message)
Zone video assign (Zone 2/Zone 3/Zone 4)
System Backup / Recovery function
Multi-channel output in main zone plus 2-channel HDMI output in a second zone
