Yamaha RX-V685 7.2-Channel 4K Ultra HD AV Receiver with MusicCast - Black
OPEN BOX Product Type
- 7.2-Channel surround sound with Zone 2
- Wi-Fi, Bluetooth, AirPlay, Spotify Connect and MusicCast multi-room. Works with Amazon Alexa.
- Pandora, Spotify, SiriusXM Internet Radio, TIDAL, Deezer, Napster and more
- HDMI 2.1 with HDCP 2.2 (5-in/2-out): 4K Ultra HD, HDR10, Dolby Vision, Hybrid Log-Gamma and BT.2020
- MusicCast Surround-capable: add two MusicCast 20 speakers to provide wireless surrounds for a 5.1-channel setup (coming July 2018).
Specs
Learn more about the Yamaha RX-V685BL
| Brand | YAMAHA |
|---|---|
| Model | RX-V685BL |
| Type | Receiver |
|---|---|
| Channels | 7.2-Channel |
| Power Output | Rated Output Power (1kHz, 1ch driven): 150W (4 ohms, 0.9% THD) Rated Output Power (20Hz-20kHz, 2ch driven): 90W (8 ohms, 0.06% THD) Maximum Effective Output Power (1kHz, 1ch driven) (JEITA): 150W (8 ohms, 10% THD) Dynamic Power per Channel (8/6/4/2 ohms): 125 / 165 / 190 / 235W |
|---|---|
| Decoder | Dolby Atmos Dolby TrueHD Dolby Digital Plus Dolby Surround DTS:X DTS-HD Master Audio |
| D/A Converter | Burr-Brown 384 kHz / 32-bit DAC x 4 for main zone |
| Audio | File Format: MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 192 kHz / 24-bit, WAV / AIFF: up to 192 kHz / 32-bit, DSD: up to 11.2 MHz Pure Direct: Yes (with video on mode) Compressed Music Enhancer: Yes (incl. enhancer for Bluetooth?) YPAO sound optimization: Yes (R.S.C) YPAO Volume Adaptive DRC (Dynamic Range Control) Initial Volume & Maximum Volume Setting Bi-amp capability Audio Delay: Yes (0-500 ms) |
| Video | 4K Ultra HD Pass-through and upscaling: Yes (4K / 60p, 4:4:4) HDMI 3D passthrough HDMI eARC: Yes (via future firmware update) HDMI Audio Return Channel HDMI upscaling: Yes (Analogue to HDMI / HDMI to HDMI) Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync |
| FM/AM Tuner | Included |
|---|
| HDMI | 5 In / 2 Out |
|---|---|
| Component Video | 1 |
| Digital Optical Audio | 2 In |
| Digital Coaxial Audio | 2 In |
| Headphone Jack | 1 |
| USB Port | 1 |
| Network Ready | Network Port |
| Wireless Connectivity | Airplay |
| Other Connectors | MusicCast Surround HDMI CEC: Yes (SCENE, Device Control) Front AV Input: USB / Mini Jack Analog Audio Input/Output: 4 (front 1) / 0 Phono Input Preout: 2.2-ch |
| Standby Consumption | <=0.1W |
|---|
| Features | Unrivaled Experiences. This 7.2-channel AV receiver boldly explores entertainment possibilities for an advanced home theater with the latest in video and audio including Dolby Atmos, DTS:X, wireless streaming, dual HDMI outputs and more. 7.2-Channel surround sound with Zone 2 Wi-Fi, Bluetooth, AirPlay, Spotify Connect and MusicCast multi-room. Works with Amazon Alexa. Pandora, Spotify, SiriusXM Internet Radio, TIDAL, Deezer, Napster and more HDMI 2.1 with HDCP 2.2 (5-in/2-out): 4K Ultra HD, HDR10, Dolby Vision, Hybrid Log-Gamma and BT.2020 MusicCast Surround-capable: add two MusicCast 20 speakers to provide wireless surrounds for a 5.1-channel setup. |
|---|
| Dimensions | 6.75" x 17.13" x 14.88" (with antenna up: 9.75" x 17.13" x 14.88") |
|---|---|
| Weight | 23.10 lbs. |
| Date First Available | January 04, 2019 |
|---|
