Item#: N82E16820227774

OCZ Z-Drive R4 CM88 3.2TB PCI-E PCI-Express 2.0 x8 MLC Enterprise Solid State Disk ZD4CM88-FH-3.2T

  • PCI-E
  • MLC
  • PCI-Express 2.0 x8
ICON Loading...

The OCZ Z-Drive R4 Series represents a turning point in the evolution of PCIe attached solid state storage by merging the best feature sets of both the pure hardware and pure software based approaches to data management. Designed and manufactured for a wide range of enterprise environments including cloud computing and data centers, the Z-Drive R4 features OCZ's Virtualized Controller Architecture (VCA) 2.0, providing the utmost in performance, flexibility, durability and enhanced reliability, allowing data centers to rely on a PCIe-based SSD as their primary tier one storage solution for the first time. Additionally, the Z-Drive R4's level of concentrated performance enables system architects to design more productive infrastructures while lowering operating costs associated with hard drive technology.

VCA 2.0 supports the industry standard SCSI command set and, among a litany of other things, provides highly efficient performance aggregation due to OCZ’s exclusive Complex Command Queuing Structure (CCQS), that handles balancing with OCZ's unique Queue Balancing Algorithm, that extends the NAND flash life at a block level, manages redundancy, and is the software interface with the host system.

Z-Drives integrate seamlessly with servers at the system bus and kernel level, creating a new flash memory tier and dramatically increasing throughput and application performance all while slashing capital and operating costs. The OCZ Z-Drive R4 Series is available in half height and full height configurations (full height form factor for CM88 version).

  • newegg The Pinnacle of Storage Performance The OCZ Z-Drive R4 Series CM88 eliminates I/O and bandwidth bottlenecks by delivering up to 2,800 MB/s Max Read/Write and 500,000 IOPS (per SuperScale controller). It delivers the performance of thousands of hard disk drives in a single server.
  • newegg Proprietary Virtualized Controller Architecture (VCA) 2.0 The OCZ Z-Drive R4 is truly unique, melding hardware and software managed solutions with integrated VCA 2.0. This brings traditional SSD technology into a new realm and enhances performance, deployment capabilities, and endurance. Included are OCZ’s exclusive command queuing and queue balancing algorithms, which can be handled by the onboard processing core for higher performance and reduced burden on the host resources. VCA 2.0 is also the only virtualization layer in the industry with TRIM and SCSI unmap support to enhance sustained performance and provide greater endurance by significantly reducing the overhead associated with garbage collection. Furthermore, VCA 2.0 offers consolidated SMART support and provides system administrators with advanced features for monitoring, analyzing, and reporting device attributes.
  • newegg SuperScale Storage Accelerator Unique to OCZ The OCZ SuperScale storage controller combines processing and full DMA (direct memory access) cores, as well as internal PCIe, SATA and SAS interfaces, facilitating scalable performance in enterprise & datacenter applications. This controller, combined with VCA 2.0 provides unique benefits to users by allowing certain DMA and data management functions including OCZ’s unique command queuing and queue balance algorithms to be handled by the onboard processing core, resulting in higher performance and reduced burden on the host resource.
  • newegg Superior Reliability, Endurance, & Security Features The OCZ Z-Drive R4 Series provides clients with world-class reliability features including superior data fail recovery, intelligent block management & wear-leveling for increased endurance, advanced security with 256-bit AES encryption support, and strong error correction for enhanced data integrity.

Learn more about the OCZ Technology ZD4CM88-FH-3.2T

General

Brand
OCZ
Series
Z-Drive R4 CM88
Model
ZD4CM88-FH-3.2T

Physical

Form Factor
PCI-E
Capacity
3.2TB
Memory Components
MLC
Interface
PCI-Express 2.0 x8
Controller
SandForce
Width
98.4mm
Depth
242mm
Height
17.14mm
Weight
262g

Performance

Max Sequential Read
Up to 2800 MB/s
Max Sequential Write
Up to 2800 MB/s
4KB Random Write
Up to 410,000 IOPS

Features

Features
Maximum IOPS: 500,000 IOPS
Random Write Operations(8kB): 275,000 IOPS

Key Differentiators:
- Highest performing enterprise PCIe solution on the market
- Merges the best features of pure hardware and software based approaches to data management and overcomes the inherent weaknesses of both
- Bootable as a direct-attach device
- Ultra-high endurance for enterprise applications (increases drive life by up to five times the rated P/E cycles of the NAND)
- Only PCIe drive with complete power fail protection & drive-level recovery
- Maintains user-configurable flexibility not found in other devices
- Only virtualization layer in the industry with TRIM and SCSI unmap support

Data Fail Recovery: Recovers data from up to one NAND flash block per NAND controller

Data Path Protection

Data Reliability: Read Unrecoverable Bit Error Rate (UBER) 10e-16

SMART Support

128-bit & 256-bit AES-compliant

PCI Express x8 or x16 slot; Fully compliant with the PCI Express Electromechanical Specification Rev. 2.0, and PCI Express Base Specification Rev. 2.0

Operating Systems: Windows Vista 32-bit/64-bit and Windows 7 32-bit/64-bit; Windows Server 2003; Windows Server 2008 R2 64-bit; Red Hat Enterprise Linux

Environmental

Power Consumption (Idle)
23W
Power Consumption (Active)
26W
Operating Temperature
0°C ~ +70°C
Storage Temperature
-45°C ~ +85°C

Quick Info

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
