Max DisplayPort 1.2 Resolution: 4096 x 2160 Max DisplayPort 1.1 Resolution: 2560 x 1600 Max DVI Resolution: 2560 x 1600
Dual-Link DVI Supported
Operating Systems Supported
Microsoft Windows 8, Windows 7, Windows XP, Windows Vista and Linux (32- or 64-bit)
Max Power: <75W Available PCI Express x16 (single slot) 2GB system memory Internet connection for driver installation
AMD Eyefinity Technology Industry-leading multidisplay technology enabling highly immersive and unrivaled multitasking experience across up to four displays, powered by a single AMD FirePro W5000 graphics card.
GeometryBoost Allows the GPU to process geometry data at a rate of twice per clock cycle resulting is a doubling in the rate of primitive and vertex processing. Triangle rates increase two-fold relative to a GPU that does not possess GeometryBoost.
DisplayPort 1.2 Simultaneously output multiple, independent audio streams and display content at resolutions beyond standard HD (maximum resolution of 4096x2160).
Energy Efficient Design AMD PowerTune technology dynamically optimizes GPU power usage and AMD ZeroCore Power technology significantly reduces power consumption at idle.
AMD ZeroCore Power AMD ZeroCore Power technology leverages AMD's leadership in notebook power efficiency to grant our desktop GPUs the ability to power down when your monitor is off, also known as the "long idle state."
AMD PowerTune AMD PowerTune is an intelligent system that performs real-time analysis of applications that utilize a GPU. In the event that an application is not making the most of the power available to the GPU, AMD PowerTune can improve that application's performance by raising the GPU's clock speed by up to 30 percent - automatically.
Video Codec Engine (VCE) A multistream hardware H.264 HD encoder, for power efficient and quick video encoding.
Form Factor & Dimensions
Full height/ half length
AMD FirePro W5000 workstation graphics card Quick Start Reference Guide AMD CrossFire Pro connector One DisplayPort to single-link -DVI (active) adapter
