| Specifications | Output Output Power Capacity: 865 Watts / 1500 VA Max Configurable Power: 865 Watts / 1500 VA Nominal Output Voltage: 120V Output Frequency (sync to mains): 47 - 63 Hz Waveform Type: Stepped approximation to a sinewave Output Connections: (12) NEMA 5-15R
Input Nominal Input Voltage: 120V Input Frequency: 50/60 Hz +/- 3 Hz (auto sensing) Input Connections: IEC-320 C14 Cord Length: 3.05 meters Input voltage range for main operations: 90 - 140V Maximum Input Current: 12A Input Breaker Capacity: 15A
Batteries & Runtime Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Included Battery Modules: 1 Typical recharge time: 16 hour(s) Typical Backup Time at Half Load: 13.4 minutes (432.5 Watts) Typical Backup Time at Full Load: 3.9 minutes (865 Watts)
Communications & Management Control panel: Multi-function LCD status and control console Audible Alarm: Alarm when on battery : distinctive low battery alarm : configurable delays
Surge Protection and Filtering Surge energy rating: 4500 Joules Filtering: Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449 Data line protection: RJ-11 Modem/Fax protection (four wire dual line), RJ45 10/100 Base-T Ethernet protection, Cable modem / Video protection, Co-axial Video / Cable protection, Coaxial 2-Way splitter with protection
Regulatory Approvals: CSA, FCC Part 15 Class B, FCC Part 68, UL 1778, UL 498 |
|---|
