Brand | BIOSTAR |
---|---|
Model | Hi-Fi Z87W |
CPU Socket Type | LGA 1150 |
---|---|
CPU Type | 4th-generation Core i5, i7 (LGA1150) |
Chipset | Intel Z87 |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR3 2800(OC)/ 2600(OC)/ 2400(OC)/ 2200(OC)/ 2133(OC)/ 1866(OC)/ 1800(OC)/ 1600/ 1333/ 1066 |
Maximum Memory Supported | 32GB |
Channel Supported | Dual Channel |
PCI Express 3.0 x16 | 1 x PCI Express 3.0 x16 |
---|---|
PCI Express 2.0 x16 | 1(x4) |
PCI Express x1 | 2 x PCI Express x1 |
PCI Slots | 2 x PCI Slots |
Serial ATA (SATA) | 6 x SATA 6Gb/s |
---|
Audio Chipset | Realtek ALC892 |
---|---|
Audio Channels | 8 Channels |
Max LAN Speed | 1Gbps |
---|
Back I/O Ports | 1 x HDMI / 2 x USB 3.0 / 4 x USB 2.0/1.1 |
---|---|
Video Ports | D-Sub + DVI |
HDMI | 1 x HDMI |
USB 3.0 | 2 x USB 3.0 |
USB 1.1/2.0 | 4 x USB 2.0 |
Onboard USB | 2 x USB 3.0 + 4 x USB 2.0 |
---|
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12" x 8.6" |
Features | Heat-Sink: SB + Mosfet Hi-Fi Technology : Hi-Fi 10Phase VRD All Solid Cap |
---|
First Listed on Newegg | September 14, 2023 |
---|
