After introducing the RAVEN Z series in 2014 to great acclaim with the revolutionary RVZ01, the RAVEN team has created another segment defining design in the RVZ02. With a volume of only 12 liters, this case is not only slimmer but is actually easier to assemble compared to the RVZ01 or any other slim case before it. Similar to many SilverStone small form factor cases, there is plenty of room for a powerful graphics card up to 13 inches in length available while tool-less drive cages have been implemented to make assembly quicker than ever. With clever space utilization and engineering, two major heat sources of a PC are separated via the chassis' main chamber so CPU and graphics card can each have their own airflow path. Despite its diminutive size, the RVZ02 is a remarkably versatile case that can be used anywhere from being a compact desktop workstation (in vertical orientation) to a living console or HTPC (in horizontal orientation), making it truly perfect for just about any slim PC build.
Independent expansion slot design for easy assembly
Acrylic window with oversized vents over CPU area (RVZ02B-W)
Support a dual-slot graphics card up to 13 inches
Hidden front I/O ports design with USB 3.0
Dual 2.5" drive slots with tool-less design
Signature RAVEN styling touches
Slim optical drive slot
|Material||Reinforced plastic outer shell, steel body|
|External Drive Bay||5.25" x 1 (compatible with 3.5" x 1 or 2.5" x 2)|
|Internal Drive Bay||3.5" x 2 (one compatible with 2.5"), 2.5" x1|
|Front I/O Port||
|Power Supply||SFX & SFX-L|
|Expansion Card||*Compatible with 13” long, width restriction – 4.78”|
|Limitation of CPU cooler||58mm|
|Dimension||380mm (W) x 87mm (H) x 370mm (D), 12 liters|
|Extra||Support two Kensington locks|
*Expansion card holder needs to be removed when installing expansion/graphics card wider than 4.78 inches. When system is assembled without the holder, vertical orientation of the case is recommended and transporting/shipping should be avoided. For more details, please refer to manual.
