Blackmagic Design Micro Studio Camera 4K CINSTUDMFT/UHD/MR

HD 1080p23.98, 24, 25, 29.97, 30, 50, 59.97, 60, 1080i50, 59.94, Ultra HD 2160p23.98, 24, 25, 29.97, 30
Shooting Resolutions
3840 x 2160, 1920 x 1080

This item is covered under the Manufacturer Only Return Policy.

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Blackmagic Design Pty. Ltd. CINSTUDMFT/UHD/MR

Model
Brand	Blackmagic Design
Model	CINSTUDMFT/UHD/MR

Details
Lens	Lens Mount Active MFT mount
Microphone	Integrated stereo microphone, active when camera is recording.
Mounting	Mounting Options 1 x 1/4" (top), 3 x 1/4" (bottom)
Specification	Standards SDI Compliance: SMPTE 292M, SMPTE 424M, Draft SMPTE 2081-1 SDI Audio Sampling: Television standard sample rate of 48kHz and 24-bit Software Software Included: Blackmagic Camera Setup Environmental Specifications Operating temperature: 0° to 40° C (32° to 104° F) Storage temperature: -20° to 45° C (-4° to 113° F) Relative Humidity: 0% to 90% non-condensing

Performance
Sensor Size	13.056mm x 7.344mm
Device Control	Iris Control Iris control via Up and Down buttons, remote control via expansion connector or ATEM Switcher CCU protocols via SDI when using compatible lenses. Controls 5 control buttons including Set, Up, Down, Menu, and Power.
Resolution Support	Shooting Resolutions 3840 x 2160, 1920 x 1080
Frame Rates/Bit Rates	HD 1080p23.98, 24, 25, 29.97, 30, 50, 59.97, 60, 1080i50, 59.94, Ultra HD 2160p23.98, 24, 25, 29.97, 30
Focus	Remote focus control via expansion connector or ATEM Switcher CCU protocols via SDI when using compatible lenses.

Connection
SDI	SDI Video Output 1 x 6G-SDI 10-bit 4:2:2 via DIN 1.0/2.3 connector. SDI Video Input 1 x 6G-SDI 10-bit 4:2:2 via DIN 1.0/2.3 connector. SDI Audio Output 2 channel embedded audio support in SDI stream.
Audio Input	1 x 3.5mm stereo audio mic or line level.
Audio Output	1 x 3.5mm stereo connector for stereo headphones, compatible with iPhone headsets for talkback.
Other Connector	Expansion Port DB-HD15 serial connector provides support for: Power input LANC input 1 x S.Bus channel input PTZ output B4 lens control output Genlock input Remote Control Remote control over SDI via ATEM Switcher CCU protocols or via expansion port using LANC or S.Bus. Computer Interface USB Mini-B port for software updates and configuration.

Compatibility
System Requirements	Operating Systems Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yosemite or later. Windows 7 or Windows 8.

Power
Power Supply	Battery Type: Canon LP-E6 (not included) Battery Life: Approximately 1 hour 10 minutes External Power Input: 12-20V

Features
Feature	The Blackmagic Micro Studio Camera 4K is an incredibly tiny Ultra HD resolution camera that can be used in HD and Ultra HD video formats that can be fully controlled from the switcher via the SDI control protocol. Blackmagic Micro Studio Camera 4K includes 6G-SDI connections, built in color corrector, talkback, tally indicator, PTZ control output, built in microphones, backup battery, an adaptable MFT lens mount and B4 lens control output.

Dimensions & Weight
Dimensions	2.57" x 3.25" x 2.74"
Weight	0.67 lb.

Package Contents
Package Content	Blackmagic Micro Studio Camera 4K Expansion cable Turret dust cap 12V AC Adapter

Additional Information
Date First Available	February 03, 2017
