Blackmagic Design Mini Converter Audio to SDI CONVMCAUDS2
- SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M-B, SMPTE 425M, ITU-R BT.656, ITU-R BT.601, SMPTE ST-2036
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Blackmagic Design Pty. Ltd. CONVMCAUDS2
| Brand | Blackmagic Design |
|---|---|
| Model | CONVMCAUDS2 |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M-B, SMPTE 425M, ITU-R BT.656, ITU-R BT.601, SMPTE ST-2036 |
|---|---|
| Video Sampling | SDI Video Sampling: 4:2:2, 4:4:4 |
| Audio Sampling | SDI Audio Sampling: Television standard sample rate of 48 kHz and 24 bit. |
| SDI | SDI Video Inputs 1 x SD, HD or 3G-SDI. 1 x ALT SDI Input for automatic switch over if main input fails. SDI Video Outputs 1 x Embedded SDI Output. SDI Redundant Input Automatically switches over if main SDI input is lost. |
|---|---|
| Digital Aduio | Digital Audio Inputs 8 channels of balanced AES/EBU audio. |
| Analog Aduio | Analog Audio Inputs 4 channels of balanced analog audio. |
| Software | Software Control Mac OS X and Windows software upgrade via USB. Internal Software Upgrade Via included updater application. |
|---|
| System Requirements | Operating Systems macOS 10.12 Sierra, macOS High Sierra 10.13 or later. Windows 8.1 or Windows 10. |
|---|
| Power Consumption | 8.40 Watts |
|---|---|
| Power Supply | +12V universal power supply included with international socket adapters for all countries. Cable tie point. Operational Voltage Range 12V DC |
| Specification | Standards SD Video Standards: 525i59.94 NTSC, 625i50 PAL HD Video Standards: - 720p50, 720p59.94, 720p60 - 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 - 1080i50, 1080i59.94, 1080i60 2K Video Standards: - 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p - 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF SDI Video Rates: SDI video connections are switchable between standard definition and high definition SDI Color Precision: 4:2:2, 4:4:4 SDI Color Space: YUV, RGB SDI Auto Switching: Automatically selects between SD, HD, and 3G-SDI Settings Control: Mini Switches or USB software Environmental Specifications: Operating Temperature: 0 to 40 celsius degree Storage Temperature: -20 to 45 celsius degree Relative Humidity: 0% to 90% non-condensing |
|---|
| Feature | Embed audio into any SDI source in SD and HD formats up to 1080p60! Audio is input as balanced analog or AES/EBU using 1/4 inch connectors from equipment such as mixers and analog decks. Mini Converter Audio to SDI is the ideal SD/HD SDI audio embedder for when you don't need the cost of the Ultra HD model! |
|---|
| Dimensions | 0.90" x 4.52" x 3.63" |
|---|---|
| Weight | 7.58 oz. |
| First Listed on Newegg | March 12, 2018 |
|---|
