4MP IR 2.8 fixed Network Turret Security Camera 3D DNR IP67 Dual-stream

4MP IR 2.8 fixed Network Turret Security Camera 3D DNR IP67 Dual-stream

This Security Camera offers an 4MP WDR Network Outdoor Turret Camera with 2.8mm Lens offers a 1/3" progressive scan CMOS, 120 dB WDR, Dual-stream, 3D DNR, Motion detection, video tampering alarm, illegal login, and Hikvision OEM

Features:
• 1/3" progressive scan CMOS
• 3D DNR (Digital Noise Reduction)
• 2560 × 1440@20fps
• Up to 30 m IR range
• 2.8 mm fixed lens
• PoE (Power over Ethernet)
• H.265+, H.265, H.264+, H.264
• IP67
• Dual-stream
• 120 dB WDR (Wide Dynamic Range)

Specifications:
• Image Sensor: 1/3" progressive scan CMOS
• Minimum Illumination: Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
• Electronic Shutter: 1/3 s to 1/100, 000 s
• Day / Night: IR cut filter
• Digital Noise Reduction: 3D DNR
• Wide Dynamic Range: 120 dB
• Angle Adjustment: Pan: 0° to 355°, tilt: 0° to 70°, rotation: 0° to 355°
• Focal Length: 2.8 mm
• Max. Aperture: F2.0
• Angle of View: horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°
• IR Distance: Up to 30 m
• Video Compression: Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG
• Video Bitrate: 32 Kbps to 8 Mbps
• Video Resolution: 2560 × 1440
• Video Frame Rate:
Main Stream:
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-stream:
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
• Image Enhancement: BLC, 3D DNR
• Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• ROI: 1 fixed region for mainstream and sub-stream
• Storage: NAS (NFS, SMB/CIFS)
• Alarm Trigger: Motion detection, video tampering alarm, illegal login
• Network Protocol: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour
• General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
• API: ONVIF (PROFILE S, PROFILE G), ISAPI
• Network Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
• Management Software: iVMS-4200, Hik-Connect, iVMS-5200
• Web Viewer: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
• Reset Button: Yes
• Operating Temperature: -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
• Power Supply: 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)
• Power Consumption: 12 VDC, 0.4 A, Max: 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W
• Ingress Protection: IP67, IK10, TVS 2000V lightning protection, surge protection and voltage transient protection
