GIGABYTE GA-EP45C-UD3R LGA 775 Intel P45 ATX Intel Motherboard

(76) Write a Review
  • Intel P45
  • Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium Dual-Core / Celeron
  • DDR3 2000(O.C)/1600/1333/1066/800 DDR2 1333(O.C)/1066/800/667
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (76)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the GIGABYTE GA-EP45C-UD3R

Model
Brand GIGABYTE
Model GA-EP45C-UD3R
Supported CPU
CPU Socket Type LGA 775
CPU Type Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium Dual-Core / Celeron
Chipsets
Chipset Intel P45
South Bridge Intel ICH10R
Onboard Video
Onboard Video Chipset None
Memory
Number of Memory Slots 6x240pin
Memory Standard DDR3 2000(O.C)/1600/1333/1066/800
DDR2 1333(O.C)/1066/800/667
Maximum Memory Supported DDR3 up to 8GB
DDR2 up to 16GB
(can not work together)
Channel Supported Dual Channel
Expansion Slots
PCI Express x16 1 x PCI Express x16
PCI Express x1 3 x PCI Express x1
PCI Slots 3 x PCI Slots
Storage Devices
SATA RAID 0/1/5/10 by ICH10R
0/1 and JBOD by GIGABYTE SATA2 Chip
Onboard Audio
Audio Chipset Realtek ALC889A
Audio Channels 8 Channels
Onboard LAN
LAN Chipset Realtek 8111C
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 1 x Optical S/PDIF Out / 1 x S/PDIF Coaxial Out / 2 x PS/2 / 8 x USB 2.0/1.1
PS/2 2
USB 1.1/2.0 8 x USB 2.0
IEEE 1394 2 x IEEE 1394a
S/PDIF Out 1 x Optical, 1 x Coaxial
Audio Ports 6 Ports
Internal I/O Connectors
Onboard USB 2 x USB 2.0/1.1 headers
Onboard 1394 1 x 1394a
Physical Spec
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 24 Pin
Additional Information
First Listed on Newegg November 24, 2008
