Brand | GIGABYTE |
---|---|
Model | GA-F2A85XM-HD3 |
CPU Socket Type | FM2 |
---|---|
CPU Type | APU (FM2 Socket) |
Chipset | AMD A85X (Hudson D4) |
---|
Number of Memory Slots | 2x240pin |
---|---|
Memory Standard | DDR3 2400(OC)/1866/1600/1333/1066 |
Maximum Memory Supported | 64GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 2 (x16, x4) |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 1 x PCI Slot |
Serial ATA (SATA) | 8 x SATA 6Gb/s |
---|---|
SATA RAID | 0/1/5/10/JBOD |
Onboard Video Chipset | None |
---|
Audio Chipset | Realtek ALC887 |
---|---|
Audio Channels | 7.1 Channels |
Max LAN Speed | 1Gbps |
---|
Back I/O Ports | 1 x D-Sub / 1 x DVI / 1 x HDMI / 1 x PS/2 / 2 x USB 3.1 Gen 1 / 3 x Audio Jacks / 4 x USB 2.0/1.1 |
---|---|
PS/2 | 1 x PS/2 keyboard/mouse port |
Video Ports | D-Sub + DVI |
HDMI | 1 x HDMI |
USB 3.0 | 2 x USB 3.0 |
USB 1.1/2.0 | 4 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 2 x USB 3.0 + 4 x USB 2.0 |
---|---|
Other Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x APU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper 1 x chassis intrusion header |
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 9.6" x 6.85" |
Power Pin | 24 Pin |
Features | GIGABYTE 3D BIOS technology with Dual UEFI BIOS design GIGABYTE Ultra Durable4 Classic technology Supports socket FM2 AMD A-series/ Athlon-series processors Enhanced AMD Radeon HD 7000-series graphics (DX11) integrated with the APU 2 PCI-E 2.0 x16 interfaces with AMD Dual Graphics, Eyefinity and CrossFire support Features HDMI/ Dual-link DVI/ D-sub ports for Triple-Monitor support 4 native USB 3.0 ports with transfer rates of up to 5Gbps 8 USB2.0 and 8 native SATA3 ports with up to 6Gbps link speed and RAID 0, 1, 5, 10 support GIGABYTE On/Off Charge technology with 3x USB power design |
---|
First Listed on Newegg | December 21, 2024 |
---|
