Question 1

is there a wifi on board?

Accepted Answer

NO But you can add a PCIe Card to obtain the same results. Visit : http://www.newegg.com/Product/ProductList.aspx?Submit=ENE&DEPA=0&Order=BESTMATCH&Description=Wifi&N=-1&isNodeId=1

Question 2

What is the minimum Watt requirement that this motherboard needs?

Accepted Answer

Motherboard power requirements would vary greatly depending on what's connected.
The more important question is will a discreet video card be used and what are it's power requirements?
What is the CPU power requirement?
How many hard drives?
SSD or conventional HDD?
The manual recommends 500W or greater.

Question 3

How many  SATA 6Gb/s cables are included in the box? Thank you.

Accepted Answer

It came with two.

Question 4

Planning on buying one for my build;  I had originally selected G.Skill Ripjaw X series ram (2x4 gb - ddr3 1600) to go with it.  However, I noticed on the specs for the ram that it is "Compatible with Intel LGA1155/LGA1156 and AMD AM3/Llano/AM3+ platforms".
Will it work with this board, or do I need to look for a different set of sticks?

Accepted Answer

That sounds like a misleading statement written by newegg. DDR3 1600 should be compatible. Check the manufacturer product page to be sure it'll work with the 1150, usually a link on the newegg page.

Question 5

Will a Intel Xeon E3-1220V3 work with this motherboard?

Accepted Answer

Theoretically, the Gigabyte Motherboard GA-H97-D3H works with Intel XEON E3-1220V3 (Frequency 3.10GHz / L3 Cache 8Mb / Core Name Haswell / Process 22mm / Stepping C0 / Wattage 80W / Model PCB BCLK 100 / Since BIOS Version F3)

Question 6

I am considering purchasing a Corsair Carbide case which has one Firewire connector to be used with this motherboard.  Does this motherboard has a firewire connection on it? Please advise. Thank you.

Accepted Answer

No Firewire. Has 4 back panel USB 3.0 ports and an internal USB 3.0 connector for 2 additional ports; also 2 back panel USB 2.0 ports and an internal connector for up to 6 more.

If you need Firewire, don't get this motherboard. But, if you're looking for front panel access to USB, it is a simple matter to get something like the "Sedna 3.5" Front Panel with 2 x USB 3.0 + 2 x USB 2.0 Ports" (I can't link but look it up on Newegg), if your case has a 3.5" opening. Just connect to the internal headers (connectors).

Question 7

ASRock Fatal1ty H97 Performance vs GIGABYTE GA-H97-D3H vs GIGABYTE GA-Z97-D3H ??

Accepted Answer

While I can't compare the ASRock I can tell you that the Gigabyte boards you are looking at are the same except one can overclock (Z97) and one can't (H97). If you are going to overclock you need to get the Z board, otherwise go with the H.

Question 8

is it goog for all games ??

Accepted Answer

Yeah, it works great if you're not overclocking. Only thing is the pins are in kind of weird spots. Overall works really really well

Question 9

GIGABYTE GA-H97-D3H or ASRock Fatal1ty H87  ? and why

Accepted Answer

H97 with better chips (audio+mb)

Question 10

GIGABYTE GA-H97-D3H vs ASRock Fatal1ty H87 ? and why

Accepted Answer

Haswell / H87 chipset had a lot of issues with Hdcp compliance and DRM
I don't think H97 is any better ... So neither is a good choice if you're gonna
Try to build a htpc or hackintosh .  If you're not going to be on iTunes for hd movies
Then it's a non issue for you , go for the newer h97

CPU Socket Type	LGA 1150
CPU Type	Celeron / Core i3 / Core i5 / Core i7 / Intel Core 4th Gen (LGA 1150) / Intel Core 5th Gen (LGA 1150) / Pentium

Number of Memory Slots	4x240pin
Memory Standard	DDR3 1600/1333
Maximum Memory Supported	32GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	1 x PCI Express 3.0 x16
PCI Express x16	1 (x4)
PCI Express x1	2 x PCI Express x1
PCI Slots	3 x PCI Slots

Serial ATA (SATA)	6 x SATA 6Gb/s
SATA Express	1 x SATA Express
M.2	1 x M.2
SATA RAID	0/1/5/10

Audio Chipset	Realtek ALC1150
Audio Channels	7.1 Channels

Meet Your Seller

GIGABYTE GA-H97-D3H LGA 1150 Intel H97 HDMI USB 3.0 ATX Intel Motherboard

Used - Good

Learn more about the GIGABYTE GA-H97-D3H

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Back I/O Ports	1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 4 x USB 3.0
PS/2	1 x PS/2 keyboard/mouse port
Video Ports	1 x DVI-D 1 x VGA
HDMI	1 x HDMI
RJ45	1 x RJ45
USB 3.0	4 x USB 3.0
USB 1.1/2.0	2 x USB 2.0
Audio Ports	6 Ports

Onboard USB	2 x USB 3.0 + 6 x USB 2.0
Other Connectors	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 3 x system fan headers 1 x front panel header 1 x front panel audio header 1 x serial port header 1 x Trusted Platform Module (TPM) header 1 x S/PDIF Out header 1 x Clear CMOS jumper

Onboard LAN
LAN Chipset	Intel i217V
Max LAN Speed	1Gbps

Physical Spec
Form Factor	ATX
Dimensions (W x L)	12.0" x 8.4"
Power Pin	24 Pin

Item#: 9SIA639KE97759
