- Supports 3rd Gen AMD Ryzen™ Threadripper™ Processors
- Quad-Channel ECC/Non-ECC Unbuffered DDR4, 8 DIMMs
- 12+2 Phases Infineon Digital VRM Solution with 70A Power Stage
- Advanced Thermal Design with Fins-Array Heat Sink
- Intel® GbE LAN with cFosSpeed Internet Accelerator
- 3 Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Thermal Guards
- Onboard Intel® WiFi 6 802.11ax 2T2R & BT 5
- 120dB SNR AMP-UP Audio with ALC1220-VB and WIMA Audio Capacitors
- RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
- Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Front & Rear USB 3.2 Gen 2 Type-C™ Header
- Q-Flash Plus Update BIOS without Installing CPU, Memory and Graphics Card
WINGS OF EXCELLENCE
- Advanced Thermal Design
- Fins-Array Heat Sink
- 5 W/mK LAIRD Thermal Conductivity Pad
- 2x Enlarged M.2 Heat Sinks
- 5cm Ball Bearing Silent Chipset Fan
- Intel® GbE LAN
- Intel® WiFi 6 802.11ax 2T2R & Bluetooth 5
- 3 x M.2 Connectors
- NVMe PCIe 4.0 x4
- With Thermal Guards
- AMP-UP Audio
- ALC 1220-VB Audio Codec
- Audiophile-Grade WIMA Capacitors
- RGB FUSION 2.0
- 2x Addressable LED Header
- 2x RGB LED Header
- Direct 12+2 Phases Infineon Digital VRM
- 8-Layer PCB
- PCIe 4.0 Ready Low-Loss PCB
- 2x Copper PCB
- Supports 3rd Gen AMD Ryzen™ Threadripper™ Processors
- Quad-Channel DDR4, 8x DIMMs with Ultra-Durable Memory Armor
- Solid Pin Power Connectors
- 24-Pin ATX Power Connector
- 8+4-Pin CPU Power Connector
- Front USB 3.2 Gen2 Type-C™
- DualBIOS™ with Q-Flash Plus
- PCIe 4.0 x16/x8/x16/x8
- 4x Ultra Durable PCIe Armor
Ultimate Power Design
To unleash the full potential of the 3rd generation AMD Ryzen™ Threadripper™ CPU, the motherboard requires the best CPU power design. With the best quality components and GIGABYTE R&D design capability, TRX40 AORUS PRO WIFI is a true beast among motherboards.
12 Phase Power Design
Direct 12+2 Phases Infineon Digital VRM Solution
TRX40 AORUS PRO WIFI motherboard uses latest new generation Infineon multiphase PWM controller, and a total 12+2 phase for vCore and SOC, all with Infineon TDA21472 Power Stage MOSFET which is capable of providing at least 70A of power from each phase, for a total of an amazing 980A. Power design is no longer a bottleneck for this motherboard.
- New Direct Multiphase Power Design
- No Doubler, Not Parallel
- Next-Gen Infineon PWM Controller
- 70A Power Stage
- The Lowest Voltage Ripple
- The Highest Efficiency
- 8+4-Pin Metal Shielding Connector
Power Efficiency & Voltage Ripple Graph
GIGABYTE's exclusive 2X copper PCIe 4.0 Ready PCBs design provides sufficient power trace paths between components to handle greater than normal power loads and to remove heat from the critical CPU power delivery area. This is essential to ensure the motherboard is able to handle the increased power loading that is necessary when overclocking.
Advanced Thermal Design
TRX40 AORUS PRO WIFI reaches a perfect balance between style and performance by combining the media acclaimed Fins-Array heat sink with pipe to provide lower MOSFET temperatures for enthusiasts, overclockers and professional gamers.
Advanced Thermal Solution
1. Fins-Array Heat Sink with Heat Pipe2. 5W/mK LAIRD Thermal Pad
Smart Chipset Fan Heat Sink
Smart Fan
Provides several different operating modes to minimize noise and extend the fan's longevity. You can choose the mode that suits you the best in any situation.
High Durability
TRX40 motherboards built-in a 5cm ball bearing fan which guarantee 50,000* working hours to cool down the heat brought out by the TRX40 chipset.
*MTBF, A standard measurement that continuously operates under certain criteria with 90% of confidence level.
AORUS M.2 Thermal Guard
GIGABYTE ULTRA-EFFICIENT M.2 THERMAL GUARD
With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling and bottlenecks from high-speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.THERMAL THROTTLING AS TEMPERATURE RISES
- Baseplate made of aluminum instead of traditional iron ensures 3X thermal conductivity.
- A thin layer of NanoCarbon is coated on the base plate through electrostatic adhesion to enhance thermal radiation capability.
- Transfer heat from the backside PCB to the baseplate so the NanoCarbon base plate can dissipate heat passively.
- Effectively lowers backside PWM component temperature by 10%.
This specialized nanostructure of carbon molecules has extraordinary thermal conductivity.
Noise Detection
With the new Noise Detection function, you can monitor noise level of all devices including fans, CPU coolers, graphics card, etc. in real time, and you can determine how fast your fan speed needs to be. Our bundled Noise Detection cable doesn't include any sound recording function, it simply detects sound pressure while protecting your privacy.
Smart Fan 5
With Smart Fan 5, users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM and Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly.
- 8x Fan/Water-Pump Connectors
- 7x Temperature Sensors
- 2x External Temperature Sensors
- All Hybrid Fan Headers
- Interoperable Fans and Sensors
- Supports High-Current Fans Up to 24W(2AX12V) with Over-Current Protection
- Intuitive UI for Fan Control
Hybrid Fan Pin Headers
Assume complete control over your liquid cooling setup! Smart Fan 5 receives up-to-the-second information on flow-rate and water-temperature through the Hybrid Fan Pin Headers or external thermistor sensors—giving you absolute mastery over your PC.- All Hybrid Fan Headers can automatically detect the type of cooling device whether it be fan or pump with different PWM or Voltage mode.
New Smart Fan 5 Software
Choose from different modes, Quiet to Full Speed, to match your system usage preferences.For each fan or pump, you can use the intuitive fan curve to define trigger thresholds and corresponding fan speeds.
ULTIMATE PERFORMANCE
TRX40 AORUS PRO WIFI pushes the envelope once again by featuring Full PCIe 4.0 Design, including PCIe 4.0 Ready PCB, PCIe 4.0 Slots, PCIe 4.0 M.2 Connectors and delivering highly optimized performance and flexibility demanded for power users and extreme gaming enthusiasts.
TRX40 AORUS PRO WIFI equips several new components to ensure the best PCIe 4.0 signal quality, including PCB, PCIe Slots, M.2 Connectors, Re-drivers, Switches that are specifically designed for PCIe 4.0. There will be no compromised on PCIe 4.0 performance.
- 2X Theoretic Bandwidth vs. PCIe 3.0
- PCIe 4.0 Switch and Re-driver IC
- New Low Impedance PCIe and M.2 Slot
- PCIe 4.0 Ready 2X Copper Low-Loss PCB
- The Best PCIe 4.0 Signal Quality
- 4x PCIe 4.0 Slot (x16/x8/x16/x8)
- 3x PCIe 4.0 M.2 Connectors (Type 22110 & 2280)
4x PCIe 4.0 Slots
Reinforced PCIe 4.0 x16/x8/x16/x8 with lower impedance.PCIe 4.0 Re-Driver
Boost & strengthen PCIe 4.0 signal to longer length.3x M.2 PCIe 4.0 Slot
M.2 PCIe 4.0 x4 slots with lower impedance.
Support for DDR4 XMP Up to 4400MHz and Beyond*
AORUS is offering a tested and proven platform that ensures proper compatibility with profiles up to 4400MHz and beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable and that the XMP function is activated and enabled on their AORUS motherboard.
Broad DDR4 Compatibility with Support List of 1,000+ DDR4 Validated!
AORUS partners very closely with memory vendors from around the world to ensure that modules offered by popular memory brands are compatible with AORUS motherboards. AORUS has verified over 1,000+ different modules to ensure performance in a AORUS built system.
Triple PCIe 4.0 M.2 Connectors with Thermal Guards
AORUS gaming motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their systems' potential.
Triple PCIe 4.0 SSD in RAID 0
Extreme Performance with PCIe 4.0 x4 NVMe PCIe SSDs
TRX40 AORUS motherboards offer the industry's best compatibility in terms of NVMe storage for users who demand high capacity and seek the best performance. AORUS' unique design can be configured in RAID for record speeds of up to 12,460MB/s (Sequential Read), making AORUS the obvious choice for the ultimate PC.
Next-Generation Connectivity
A high-end product needs to be future-proof so your system stays up-to-date with the latest technology. TRX40 AORUS PRO WIFI provides next-generation network, storage, and WiFi connectivity to keep you up to speed.
Intel® GbE LAN with cFosSpeed Internet Accelerator Networking
Intel® GbE LAN features cFosSpeed, a network traffic management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments.
All-New Intel® WiFi 6 802.11ax + Bluetooth 5 Module
This Intel Wireless solution supports 802.11ax, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps.* Moreover, Bluetooth 5 provides 4X range over Bluetooth 4.2 and with faster transmission.Benefit of WiFi 6:
- 5.5X better throughput than 802.11ac 1x1*
- 4X better network capacity, no traffic jams especially in those dense area with lots of devices
- Network efficiency increase for better user experience
AORUS Antenna Supports Dual Band with Better WiFi Signal
- All-new antenna supports dual-band 802.11ax/ac 2.4GHz & 5GHz;
better signal strength compared to traditional antenna design - AORUS Antenna with smart antenna function for the best WiFi signal transmitting
- Multiple angle tilt and magnetic base for the best signal strength direction and location
Native USB 3.2 Gen2
CONNECTING THE FUTURE: USB TYPE-C™
AMD's native USB 3.2 Gen2 provides USB 3.2 Gen2 ports with speeds up to 10Gbps. With twice the bandwidth compared to its previous generation as well as backwards compatibility with USB 2.0 and USB 3.2 Gen1, the much improved USB 3.2 Gen2 protocol is available over the new reversible USB Type-C™ and the traditional USB Type-A connector for better compatibility over a wider range of devices.
USB Type-C™ Front-Panel Connector
Equipped with next-generation connectivity GIGABYTE motherboards already support the chassis of the future. The onboard USB Type-C™ header for USB 3.2 Gen2/ Gen1 makes access convenient when connecting a USB 3.2 drive or charging your new mobile device.
AORUS AESTHETICS
TRX40 AORUS PRO WIFI features RGB FUSION 2.0 and offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique and stylish.
RGB FUSION 2.0
Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support and a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.
With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style and show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.
GIGABYTE RGB Fusion APP
Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try and adjust colors and speeds for different modes, all this can be achieved away from the keyboard and monitor of their PC.
AORUS AUDIO
ALC1220-VB Immersive Gaming Vibes
All-New Realtek High-End HD Audio Codec
ALC1220 120dB(A) SNR HD Audio with Smart Headphone Amp automatically detects impedance of your head-worn audio device, preventing issues such as low volume and distortion.With the new VB series audio controller, stream your voice to the world vibrantly with both front/rear microphone SNR up to 110/114dB(A).
No More Confusion During In-Game Voice Chat
Microphone input with higher front dynamic range allows gamers to hear more clearly. No more misunderstandings, no more confusing GO! GO! GO! as NO! NO! NO!
Hi-Fi Grade WIMA Audio Capacitors
TRX40 AORUS motherboards feature Hi-Fi grade WIMA FKP2 capacitors which are used as feedback signal processing to deliver crystal and balanced sound and are also being used widely in premium grade Hi-Fi systems. The addition of this to the exclusive AORUS AMP-UP Audio technology makes for the ideal onboard sound solution for the most demanding audiophiles
DTS :X® Ultra
Recreates an authentic, spatially accurate 3D audio experience for gaming over any headphones or speakers. Supports channel-based, scene based and object-based audio. Provides out-of-the-box calibration for a range of headphones and speakers. Provides post-processing enhancements and device level tuning for DTS® codecs.
DTS Sound Unbound* leverage Microsoft Spatial, enabling the the most believable, 3D audio experience for games. Immersion through DTS Headphone:X means in the sonic landscape, stationary and moving sounds can be heard from above, below or around the listener. Sounds pass around the listener with amazing externalization and accurate localization.
DTS:X Ultra Technology Video
DTS:X Ultra Experience Video
ULTRA DURABLE
GIGABYTE is reputable for its durability and high quality manufacturing process. Needless to say, we use the best components we can find on TRX40 AORUS PRO WIFI and reinforce every slot to make each of them solid and durable.
Ultra Durable™ PCIe Armor
INDUSTRY-LEADING ULTRA DURABLE™ PCIe ARMOR
The innovative one piece stainless steel shielding design from GIGABYTE reinforces the PCIe connectors to provide the extra strength required to support heavy graphics cards.
Ultra Durable™ Memory Armor
AORUS' exclusive one piece stainless steel shielding design prevents against PCB distortion/twisting and plate bending, in addition to preventing any possible ESD interference.
Solid Pin Power Connectors
TRX40 AORUS motherboards feature solid plated ATX 24pin & ATX 12V 8-pin + 4-pin power connectors to offer a stable power supply during CPU overloading.
Solid Pin Power Connector Advantages
- Larger contact area for electricity
- More metal quantity to sustain higher power and generated heat
- Ultra durable and longer lifespan
Q-Flash Plus
Update the BIOS easily without installing the CPU, memory and graphics card.
With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory and graphics card nor enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you're good to go!
GIGABYTE-Patented Double-Locking Bracket
GIGABYTE Patented DualBIOS™ Design
GIGABYTE Ultra Durable™ motherboards feature GIGABYTE DualBIOS™, an exclusive technology from GIGABYTE that protects arguably one of your PC's most crucial components, the BIOS. GIGABYTE DualBIOS™ means that your motherboard has both a "Main BIOS" and a "Backup BIOS", protecting users from BIOS failure due to virus, hardware malfunction, improper OC settings or power failure during the update process.
Diagnostic LEDs
Onboard LEDs controlled by the system BIOS indicate if a malfunction is occurring, allowing users to quickly diagnose which major component (CPU/DDR/VGA/HDD) is malfunctioning so they may take action promptly.
*Photo for reference only.
Easy-to-Install "G Connector" Design
The tiny cables of the front panel connectors can be hard to manipulate as space is restricted and indicators are tiny. With the G Connector, you can connect all the FP cables at once, simplifying the process of building your next PC and saving you frustration.
GIGABYTE BIOS & APP CENTER
Good software goes hand in hand with perfect hardware. TRX40 AORUS PRO WIFI bundled several useful and intuitive software to help users to control every aspect of motherboard.
BIOS
NEW USER INTERFACE
All-new EASY MODE shows important hardware information in one page including CPU clock, memory, storage and fan.
MY FAVORITES
Add constantly used items into the favorite menu for quick access.
STORAGE INFORMATION
Show all kinds of storage information including SATA, PCIE and M.2 interface.
CHANGELOG
List all changes before saving and exiting bios. Quickly review overall settings modification.
OPTIMIZED MEMORY-INSTALLATION REMINDER
Displays correct installation reminder message when user installs two memory modules but runs single-channel mode.
INTUITIVE LOAD-LINE CURVE
Clearly show each load-line calibration setting in an intuitive curve graph.
APP CENTER
GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities and drivers, you can choose any utility you want to install from APP CENTER and keep updated with the latest utilities and drivers version.
EasyTune
GIGABYTE's EasyTune™ is a simple and easy-to-use interface that allows users to fine-tune their system settings or adjust system and memory clocks and voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.
System Information Viewer
GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks and processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.
XSplit Gamecaster + Broadcaster: Cast Your Game Anytime, Anywhere
Now set up your stage and share the greatest gaming moments with XSplit Gamecaster + Broadcaster! Fully optimized social media integration is ready for real-time chats—keeping you notified yet focused in the game. It takes just one click to stream your gameplay to Twitch. Host your game like a pro!*Free 1 year XSplit Gamecaster + Broadcaster Premium License.
- Enjoy 3 days FREE seamless connection to any game server in the world
- Experience up to 60% overall connection improvement
- Receive FREE unlimited access to PC Gaming Launchpad, supporting over 800 MMO games
- Monitor your Game Ping and Connection Statistics continuously
