Specifications: Long-Distance Data Transfer to 4 Devices - Up to 164 ft. (50 m) from the Source
Send data to as many as four USB 2.0 devices located up to 164 ft. from the source
USB signals travel over a single user-supplied Cat5/Cat6 cable
Includes transmitter with built-in USB-A cable and 4-port receiver hub
Supports data transfer rates up to 480 Mbps
Greater Distance over Cat5/Cat6 Cable Provides Greater Flexibility
Cat5/Cat6 cabling exceeds the 16 ft. distance limitation of USB cables
Allows connection to devices that lack network connectivity in areas beyond the reach of standard USB cables
Makes connections in areas without network availability
Allows source to be in a secure location, separate from peripherals
Cat5/Cat6 cabling is cost-effective and readily avai...
Specifications: Cabling: Cat 5 UTP or better
Ports: 1
Max Distance: 50 m / 165 ft
Maximum Data Transfer Rate: 480Mbps
MTBF: 72,000 Hours
OS Compatibility: OS Independent; No additional drivers or software required
System and Cable Requirements:
A host computer with an available USB-A port (USB Type-A)
Terminated RJ45 Cat5e or better Ethernet cable
LED Indicators: 1 x Power / Link
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 - 240 AC
Output Current: 2 A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 10
Power Source: AC Adapter Included
Enclosure Type: Steel
Specifications: The 1-Port USB 2.0 Over Cat5/Cat6 Extender is a perfect solution for conference rooms and huddle spaces in need of a innovatively simple, yet powerful solution for extending USB signals beyond their native 16.4 foot length limitation.
Convenience
Plug and play installation is quick and easy with no software or drivers required. Reduce cable clutter by running a single Cat5/Cat6 cable to a remote location, or for added convenience, use existing in-wall Cat5/Cat6 cabling to extend USB connections between rooms.
Performance
Using USB 2.0 speed and power, this solution provides increased bandwidth and faster data transfer speeds, up to 480Mbps, over standard Cat5/Cat6 cabling at lengths up to 150ft. The included 5V2A DC power supply provides enough power to...
Specifications: Audio: Yes
AV Input: HDMI
AV Output: HDMI
Cabling: Cat 6 UTP
Chipset ID: Norelsys NS 5730, NS5731
Audio Specifications: 7.1 Surround Sound
Max Distance: 140 m / 460 ft
Wide Screen Supported: Yes
Supported Resolutions:
3840x2160 (4K) 60Hz
2560x1600 60Hz
1920x1200 60Hz
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
*Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Center Tip Polarity: Positive
Input Voltage: 110V-240V AC
Output Current: 3 A
Output Voltage: 5V DC
Plug Type: M
Power Source: 2 AC Adapters Included
Specifications: Long-Distance Data Transfer to 1 Device—Up to 164 ft. (50 m) from the Source
Send data to a USB 2.0 device located up to 164 ft. from the source
USB signals travel over a single user-supplied Cat5/Cat6 cable
Includes transmitter with built-in USB-A cable and a 1-port receiver
Supports data transfer rates up to 480 Mbps
Greater Distance over Cat5/Cat6 Cable Provides Greater Flexibility
Cat5/Cat6 cabling exceeds the 16 ft. distance limitation of USB cables
Allows connection to devices that lack network connectivity in areas beyond the reach of standard USB cables
Makes connections in areas without network availability
Allows source to be in a secure location, separate from peripherals
Cat5/Cat6 cabling is cost-effective and readily available
For best resul...
Package Contents: B126-1A0 HDMI Over Cat5 Active Extender Remote Unit
Screwdriver for adjustment of Equalization
Mounting hardware
External power supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
Owner's manual
Specifications: Audio: Yes
AV Input: HDMI
Cabling: Cat 5 UTP or better
Daisy-Chain: No
Ports: 1
Audio Specifications: Supports Dolby TrueHD, DTS-HD MA
IR Interface: Bi-directional, 38Khz / +/-10° / 5M
Max Distance: 50 m / 165 ft
Maximum Data Transfer Rate : HDMI - 3.4Gbps, RS232 - 115200bps baud
Maximum Digital Resolutions: 1080p @ 60Hz, 48-bit
Wide Screen Supported: Yes
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports : HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Supported Resolutions: 1280 x 720 (720p); 1920 x 1080 (1080p); 3840 x 2160 (4K)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Max. Distance (Between any 2 Units): 230 ft.
Maximum Distance with Booster: 400
Receiver/Transceiver Video Output: HDMI
Receiver - Number of Video Outputs: 1
Max Supported Color Depth: 36-bit Deep Color
HDR Support: Yes
3D Video Supported: Yes
Chroma Sub Sampling: 4:4:4
Maximum Signal Range (m): 70
HDCP Specification: 2.2
Driver Required: No
Recommended Category Cable: 26AWG STP Cat6/6a
EMI/RFI Line Noise Protection: Yes
DIN Mountable: No
Integrated/Removable Cable: No
Includ...
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Video Ports: HDMI (FEMALE); (4) RJ45 (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio Specification: True uncompressed 7.1 Channel digital audio and supports DTS-HD, Dolby-TrueHD digital audio
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 2
Video Ports: (2) HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 1.4; HDCP 2.2
Resolutions Supported: 3840 x 2160 (4K x 2K) @ 60 Hz (both Local HDMI port and HDMI Output)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio Ports: HDMI (FEMALE)
Audio Ports Details: HDMI outputs support passthrough audio formats including LPCM2.0/5.1/7.1
Audio Input: HDMI
Audio Output: HDMI
Audio Specification: HDMI outputs support passthrough audio formats including LPCM2.0/5.1/7.1
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports: HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 1.4; HDCP 2.2
Supported Resolutions: 1280 x 720 (720p); 1920 x 1080 (1080p); 3840 x 2160 (4K)
Max Supported Video Resolution: 3480 x 2160 @ 60 Hz
Max. Distance (Between any 2 Units): 230 ft.
Maximum Distance with Booster: 400
Transmitter Video Input: HDMI
Transmitter - Number of Video Outputs: 1
Transmitter - Local Display Output: HDMI
Receiver/Transceiver Video Output: HDMI
Receiver - Number of Video Output: 1
Max Supported Color Depth: 36-bit Deep Color
HDR Support: Yes
3D Video Supported: Yes
Chroma Sub Sampling: 4:4:4
Maximum Signal Range (m): 70
HDCP Specification: 1.4; 2.2
Driver Required: No
Recommended...
