Specifications: Industry Standards:
- USB 3.0 Specification Rev. 1.0
- USB Battery Charging Specification Rev. 1.2 (Apple Mode only)
- PCI Express Base Specification Rev. 2.0
- Intel xHCI Specification Rev. 1.0
Interface: USB 3.0
Connector Type(s): 1 - PCI Express x4 Male
External Ports: 4 - USB 3.0 A (9 pin; SuperSpeed) Female
Internal Ports:
- 1 - LP4 (4 pin; Molex Large Drive Power) Female
- 1 - SATA Power (15 pin) Plug
Maximum Cable Length: 9.8 ft [3 m]
Maximum Data Transfer Rate: 5Gbps per 2 ports - 10Gbps Total
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Specifications: Cable Length (m): 0.064008
Input Plug Type: USB A (Male)
Side A - Connector 1: USB 3.0 A (MALE)
Side B - Connector 1: 22 PIN SATA + POWER (FEMALE)
System Requirements:
Device with USB port (USB 3.0 required for USB 3.0 speeds)
UASP-enabled host controller required for UASP performance
2.5 in. SATA HDD or SSD with 9.5 mm maximum height
Type: Office Products
Weight: 0.35
Package Contents: U357-025-UASP USB 3.0 SuperSpeed External 2.5 in. SATA Hard Drive Enclosure
USB 3.0 Micro-B cable, 1 ft.
Owner’s manual
Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Package Contents: Dual-Bay SATA HDD Docking Station for 2 x 2.5/3.5" SATA SSDs/HDDs - USB 3.0
1 x USB 3.0 Cable
1 x Universal Power Adapter (NA/JP, UK, EU, ANZ)
1 x Quick-start Guide
Specifications: Chipset ID: JMicron - JMS580
Drive Size: 22mm - M.2 SATA
Supported Drive Height(s): 2242 / 2260 / 2280
Compatible Drive Types: M.2 (SATA, B-Key, NGFF) / M.2 SATA (NGFF, B+M-Key)
Maximum Data Transfer Rate: 6 Gbps
MTBF: 50,000 hours
TRIM Support:Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
Drive Connectors: 1 - M.2 (SATA, B-Key, NGFF) Receptacle
Host Connectors: 1 - USB Type-C (24 pin) USB 3.1 (10Gbps) Male
Note:
Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices.
Specifications: System Requirements:
Any USB-enabled operating system
Available USB-C port (USB 3.1 required to achieve USB 3.1 speeds)
2.5 in. or 3.5 in. SATA drive
UASP-enabled host controller required for UASP performance
Operating Temperature Range: 50 to 122 degree F (10 to 50 degree C)
Storage Temperature Range: 32 to 149 degree F (0 to 65 degree C)
Specifications: Host Interface: SFF-8643
Device Interface: SFF-8639
Data Transfer Rates: Up to 4GB/s (PCI Express 3.0)
Port Types: SFF-8643 to U.2 SFF-8639 connector with 15-pin SATA Power Connector
Length: 0.5 Meter
Packaging Contents: 1 x cable
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
HDD Capacity: Up to 8TB
Power Supply: Ac Adapter
Material: Plastic
Dimensions: 63.00 x 42.00 x 14.00 mm
USB cable Length: 457.00 mm
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: Adapter:
Device Support: SATA III/II/I SSD/HDD
Device Size: 2.5" SSD/HDD
SATA Interface: Standard SATA
USB Interface: USB 3.0 Type A (Backwards Compatible with USB 2.0)
HDD Capacity: Up to 2TB (Check www.vantecusa.com for any updates)
Material: Plastic
Power: USB Bus Powered
Casing:
Device Support: SATA III/II/I SSD/HDD
Device Size: 2.5", Thickness: 9.5mm
Material: Plastic
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10
Mac OS X v10.4 and Up
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
For UASP, the OS must have Support for UASP Protocol
Drive Compatibility: • 12 x 3.5 or 2.5" SATA HDD/SDD (drives not included)
• Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list.
The use of non-validated components may limit certain functionality and result in data loss and system instability
Power: AC input power voltage : 100 V to 240 V AC
Temperature: • Operating Temperature: 0°C to 35°C (32°F to 95°F)
• Storage Temperature: -20°C to 60°C (-5°F to 140°F)
Humidity: • Operating Relative humidity: 8% to 80% RH Storage environment
• Storage Relative humidity: 5% to 95% RH
Specifications: System Requirements
Any USB-enabled operating system
Available USB port (USB 3.0 required to achieve USB 3.0 speeds)
2.5 in. SATA drive
UASP-enabled host controller required for UASP performance
Operating Temperature Range: 50 to 122 degree F (10 to 50 degree C)
Storage Temperature Range: 32 to 149 degree F (0 to 65 degree C)
