Dimensions: Mechanical & Electrical Properties
Folded: 236×64×316 mm (L×W×H, excluding the tripod and the Quick-Release Plate)
Unfolded: 175×182×338 mm (L×W×H, excluding camera, tripod, and the Quick-Release Plate)
Weight: Mechanical & Electrical Properties
Gimbal: Approx. 890 g (2 lbs) (including the Quick-Release Plate and excluding the tripod)
Extended Grip/Tripod: Approx. 140 g (0.3 lbs)
Image Sensor: Type: 4/3'' Live MOS sensor
Effective pixels: 20.3 Megapixels
Full resolution: 21.8 Megapixels
Aspect ratio & area: 4:3 / 17.3 x 13.0mm
Filter array: Primary colour filter (RGB)
Viewfinder Type: Electronical Viewfinder
ISO Sensitivity: Auto: ISO LOW* - 6400
Note: *approx. 100
Manual: ISO LOW - 25600 (adjustable in 1/3 EV step)
Shutter Speed: Shutter speed range: 1/4000 - 60s (in 1/3 EV steps)
Bulb mode: Up to 30 minutes (selectable longest time in the menu, default: 8 minutes)
Shutter type: Electronic first curtain shutter
Shutter speed: 1/320* - 60s
Note: * For speeds over 1/320 sec., mechanical shutter will automatically be selected.
Shutter type: Electronic shutter
Shutter speed: 1/16000 - 60s
