HUBBELL WIRING DEVICE-KELLEMS HBL2311SW Watertight Locking Plug, L5-20P, 20 A,

The HUBBELL 20A Watertight Twist-Lock Plug (L5-20P) is a locking plug rated for use in specified environments. Rated for 20 amps and 125V AC, this plug features an IP66 rated enclosure to protect against moisture, dust, and weather exposure during use. Its twist-lock design intended to maintain connection during operation reduces the risk of accidental disconnection and limits arcing when connecting or disconnecting under load.

Key Features of the HUBBELL 20A Watertight Twist-Lock Plug:

• Current/Voltage Rating: Designed for 20 A at 125V AC; single phase


• Construction: Impact-resistant housing made from polybutylene terephthalate (PBT); shrouded design protects blades from bending or breaking


• Cord Accommodation: Accepts cord diameters from 0.36 in to 0.93 in; suitable for wire sizes ranging from 16 AWG to 8 AWG


• Connection Type: Screw terminals with standard wiring style; polarized and grounded configuration


• Material Details: Brass blades and contacts; stainless steel screws; clear polycarbonate retainer


• Operating Temperature Range: -40°C to +75°C maximum operating temperature


• Chemical Resistance: Chemical- and impact-resistant materials


• Flammability Rating: UL94 V-0 rated materials used throughout construction


• Ingress Protection & Standards: IP66 rated; CSA Certified Type 4 and UL Listed compliance
