Learn more about the Kingston Technology Corp. SUV500MS/120G
Model| Brand | Kingston |
|---|
| Series | UV500 |
|---|
| Model | SUV500MS/120G |
|---|
| Part Number | SUV500MS/120G |
|---|
| Device Type | Internal Solid State Drive (SSD) |
|---|
| Used For | Consumer |
|---|
Details| Form Factor | mSATA |
|---|
| Capacity | 120GB |
|---|
| Memory Components | 3D TLC |
|---|
| Interface | SATA III |
|---|
| Controller | Marvell Dean |
|---|
Performance| Max Sequential Read | Up to 520 MBps |
|---|
| Max Sequential Write | Up to 320 MBps |
|---|
| 4KB Random Read | Up to 79,000 IOPS |
|---|
| 4KB Random Write | Up to 18,000 IOPS |
|---|
| MTBF | 1,000,000 hours |
|---|
Features| Features | Kingston's UV500 SSD dramatically improves your system's responsiveness with incredible boot, loading, and transfer times compared to mechanical hard drives. It uses a Marvell Dean controller and 3D NAND Flash to power through daily tasks and improve productivity. UV500 also provides end-to-end data protection using 256-bit AES Hardware-based encryption and support for TCG Opal 2.0 security management solutions. The UV500's available in multiple capacities from 120GB - 960GB giving you options to meet your system's needs.
10X faster than a 7200 RPM hard drive
AES 256-bit Hardware Encryption Self-Encrypting Drive (SED) and TCG Opal 2.0
Available in multiple form factors (2.5"/M.2/mSATA)
Multiple capacities up to 960GB
Total Bytes Written (TBW): 60TB |
|---|
Environmental| Power Consumption (Idle) | 0.195W |
|---|
| Power Consumption (Active) | 1.17W (MAX) Read / 2.32W (MAX) Write |
|---|
| Operating Temperature | 0°C ~ +70°C |
|---|
| Storage Temperature | -40°C ~ +85°C |
|---|
| Max Vibration Resistance | Operating: 2.17G Peak (7 - 800 Hz)
Non-operating: 20G Peak (10 - 2000 Hz) |
|---|
Dimensions & Weight| Height | 4.85mm |
|---|
| Width | 29.85mm |
|---|
| Depth | 50.80mm |
|---|
| Weight | 6.20g |
|---|
Additional Information| Date First Available | November 11, 2022 |
|---|
