The 12 Gbps Adaptec SmartRAID 3154-8e RAID adapter has 8 external SAS/SATA ports in a x8 PCIe Gen 3 low-profile, MD2 form factor. Microchips industry leading Smart Storage stack delivers maximum reliability and best-in-class performance that all RAID levels come to expect, plus unique features like Mixed Mode support (RAID and HBA devices can be used simultaneously), adapter power management (reduces power consumption up to 30 percent), and Advanced Data Management (ADM) features that allow data migration from existing RAID arrays.
SmartRAID 3154-8e adapters include maxCache 4.0, and when coupled with 12 Gbps SSDs, provide maximum read/write bandwidth and IOPS as well as acceleration and latency optimization through caching. The SmartRAID 3154-8e adapters also integrate flash-based cache backup to enable instant cache protection. The tethered ASCM-35F capacitor module ensures data is safely backed up to Flash memory in case of power loss.
With broad operating system support and ecosystem compatibility, SmartRAID adapters are easy to implement and scale, and the unified maxView management tools and drivers across the Microchip HBA, RAID, and expander solutions enable easy manageability across the entire product line.
SmartRAID 3154 RAID adapters are ideal solutions for high performance enterprise servers that require maximum connectivity and security.
Learn more about the Microsemi 3154-8e
Model
Brand
Microsemi
Model
3154-8e
Part
2290800-R
Form Factor
MD2 - Low Profile
Details
Type
SATA / SAS
External Connectors
2 x SFF-8644 mini-SAS HD
Interface
PCI-Express 3.0 x8
Transfer Rate
Up to 12Gb/s
Cache Memory
4GB DDR4 / 2100 MHz
Operating Systems Supported
Microsoft Windows Red Hat Linux SUSE Linux Debian Linux Ubuntu Linux Solaris FreeBSD VMware ESXi Citrix XenServer
Dimensions
2.54" x 6.60" (H x L)
Features
Features
Ideal for enabling 12 Gbps storage capabilities in performance-hungry server and workstation platforms, without compromising proven Microsemi reliability
Provides high I/O transaction and high bandwidth processing solutions that reduce energy consumption and maintenance costs
Accelerates storage with up to 4GB of highspeed DRAM cache with integrated cache protection (SmartRAID 315x SKUs only)
