Amlogic S905X3 TV Box Android 9.0 4GB RAM 32GB EMMC Set Top Box HDMI 2.4G 5G WIFI Bluetooth 4K Media Player Vs X96 Max

Feature:

Amlogic S905X3 Quad core ARM Cortex-A55 CPU - GPU: ARM G31 MP2 GPU   - RAM:  4GB    - ROM: eMMC Flash 32GB    - Android 9.0 OS   - Video Output UHD 4K and Hardware Decoding   - 2.4G/5GHz Dual Band WiFi,  Bluetooth Wireless Connection   - 1000M LAN Ethernet RJ45

Techonolgy Data

Model No.:

TOX 1

Model Name:

Android TV-Box

Hardware Spec:

Operation System

Android 9.0

Language

Chinese,English...Multi-Language support

CPU

S905X3)Quad core ARM Cortex-A55 CPU 1.9GhZ

GPU

ARM G31 MP2 GPU

RAM

4GB

Flash

32GB (EMMC)

Network

IEEE 802.11 a/b/g/n 2.4GHz / 5.0GHz(option)

WIFI Module

RTL8822BS(IEEE802.11a/b/g/n/ac, 2.4G&5.8G dual-band WiFi)

WiFi Antenna

2T2R, 1 inner and 1 external

LED indicator

led penal, Blue when Power on

The extended storage

Card, up to 128GB (SD2.X,SD3.X,SD4.X, eMMC ver5.0)

CEC

support

RTC

support

Power Supply

DC 5V/2A

HDR

support

Interface:

HDMI Output

HDMI(1.4 and 2.0 ) to support maximum 4K@60fps output(HDCP2.2)

USB Port

1*USB 2.0 OTG + 1*USB 3.0 host

Data Output

1*SPDIF

Led work light

support

Network

1*RJ45 1000M (Gigabit network)

Power Supply

1*Micro usb

Media Parameter:

Audio Container

MP3,AAC,WMA,RM,FLAC

Audio Out

Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable 7.1/5.1 Built-in SPDIF/IEC958 output and PCM input/output Built-in stereo audio DAC

Video CODEC

Software Extension
