Yorkville YXL10P | 10in - 126dB

The YXL cabinets use a single driver and 90 x 60 degree horn with 1-inch throat and 1-inch compression driver. Constructed from strong Polypropylene YXL is poised to uphold Yorkville\'s reputation for reliability and durability. The cabinets can be positioned upright or used as a monitor wedge.

Designed as an all-purpose speaker with the Musician & DJ in mind each YXL cabinet features 3 channels. The cabinet supports Bluetooth streaming and EQ pushbutton controls for Concert Club & Monitor modes.

Features:
1000 Watts (Peak) 500 Watts (Program)
10-inch woofer with 2-inch voice coil
3 Channels plus Master level
1-inch compression driver
90° x 60° HF dispersion
Polypropelene cabinet construction
Integrated 3 channel mixer with 2X 1/4" 2X XLR and 1/8" inputs
Bluetooth streaming
3 performance modes (Concert Club Monitor)

Specifications

:
System Type Active Loudspeaker
Active or Passive Active
Program Power (Watts) 500 Watts Program (1000 Watts Peak)
Max SPL (dB) 126dB Peak
Frequency Response (Hz +/- 3dB) 55 - 16k (Hz +/-3dB)
90 x 40
Crossover Frequency (Hz) 1.6 kHz
HF Horn Integrated into Baffle
LF Driver (s) 10-inch (2-inch voice coil)
LF Program Power (Watts) 450 Watts Program (900 Watts Peak)
HF Power Amplifier (Watts) 50
HF Amplifier Type Class A/B
LF Amplifier Type Class D
Cooling Scheme Speed controlled fan
Power Cable Yes
Power Switch Yes
Inputs 2 x XLR 2 x 1/4" 1/8" Bluetooth and Main in (XLR)
Level Controls x3 Chanels + Master
EQ Controls Push button select Concert Club Monitor
Limiter Multiband excursion RMS rail
Other Controls / Features Sub mode HP filter Mixer IN/OUT Stereo/Mono out 3.5 mm Aux in BT streaming
Feet Rubber
Bar Handles 1 x Side / 1 x Back
Flying Hardware 2 (Top) 1 (Pullback)
Optional Flying Hardware Yes
Enclosure Materials Polypropelene Metal grille
Baffle Material Polypropylene
Grille Powder Coated Steel with Grille Cloth
Other

Details

Rubber feet
