HP Aruba 2920-48G Switch Managed Rack-mountable 44x 10/100/1000 + 4 x combo Gigabit SFP J9728A#ABA
Condition: Refurbished
(Included: Switch, Cables, Mount bracket, Manual.)
Compeve SKU: 101000158013
Specification:
The Aruba 2920 Switch Series provides security, scalability, and ease of use for enterprise edge, SMB and branch office networks. A powerful ProVision ASIC delivers low latency,
more packet buffering, and adaptive power consumption. This Layer 3 switch series supports modular stacking, 10GbE, PoE+, static and RIP routing, Access OSPF routing, Tunneled Node, ACLs, sFlow, and IPv6. The 2920 delivers a consistent wired/wireless user experience with advanced security and network management tools with Aruba ClearPass Policy Manager and Aruba AirWave. With support from Aruba Central, you can quickly set up remote branch sites with little or no IT support.
The Aruba 2920 Switch Series provides cost-effective pay as you grow modular stacking with a 2-port stacking module, support for up to four 10GBASE-T (or SFP+) uplinks and upgradeable power supplies so your network can quickly scale when needed.
Model - 2920-48G
PN - J9728A#ABA
I/O Ports and slots
44 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3 Type 10BASE-T
IEEE 802.3u Type 100BASE-TX
IEEE 802.3ab Type 1000BASE-T
Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
4 RJ-45 dual-personality
10/100/1000 ports
IEEE 802.3 Type 10BASE-T
IEEE 802.3u Type 100BASE-TX
IEEE 802.3ab Type 1000BASE-T
2 module slots
Additional ports and slots
1 stacking module slot
1 dual-personality (RJ-45 or USB micro-B)
1 USB 1.1
1 RJ-45 out-of-band management port
Power supplies
J9739A (HPE X331 165W 100-240VAC to 12VDC Modular Power Supply)
Dimensions & Weight
17.42 x 13.23 x 1.73
11.95 lb
Memory and Processor
Tri Core ARM1176 @ 625 MHz,
512 MB SDRAM; Packet buffer size: 11.25 MB
(6.75 MB dynamic egress + 4.5 MB ingress), 1 GB flash
Performance
100 Mb Latency
1000 Mb Latency
10 Gbps Latency
Throughput up to 130.9 Mpps
Switching capacity 176 Gbps
Routing table size 2048 entries (IPv4), 256 entries
MAC address table size 16000 entries
Environment
Operating temperature 32°F to 131°F (0°C to 55°C)
Operating relative humidity 15% to 95%, noncondensing
Nonoperating/Storage temperature -40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity 15% to 95%, noncondensing
Altitude up to 10,000 ft (3 km)
Acoustic Power: 57 dB, Pressure: 41.8 dB
