| Video Compression |
H.264+/H.264/H.265/H.265 Pro+ |
| Video Input |
8CH Analog HD/Analog + 2CH IP Video (up to 12 channel when IP enhanced mode on) |
| Video Output |
HDMI and VGA Up to 1080P |
| Audio Input |
1-ch RCA, 8-ch via coaxial cable |
| Audio Output |
1-ch RCA |
| Supported Camera Types |
"Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p;Support AHD Input: 5MP(20FPS)4MP, 1080p, 720P;Support CVI Input: 5MP(20FPS),4MP, 1080p, 720P; |
| Support CVBS Input; |
Support IP Video Input:6MP/5MP/4MP/3MP/1080P/720P |
| Analog HD Playback Resolution |
3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps |
| IPC Playback Resolution |
Up to 6MP |
| Max Playback Channel |
8-ch |
| Network Protocols |
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS |
| Total Bandwidth |
96Mbps |
| Remote Connection |
64 |
| Motion Detection 2.0 |
All analog channels support human and vehicle detection to reduce false alarm |
| HDD |
1 SATA interface |
| HDD Capacity |
Up to 10TB capacity |
| Network interface |
1, RJ45 10M/100M self-adaptive Ethernet interface |
| USB |
USB2.0x2 |
| Operating Power |
DC12V |
| Dimensions(W x H x D) |
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
| Weight (without hard disk) |
2.2 lb |
| Image Sensor |
2MP CMOS Image Sensor |
| Video Resolution |
1920 (H) X 1080 (V) |
| Signal System |
PAL/NTSC |
| Frame Rate |
PAL: 1080p@25 fps NTSC: 1080p@30 fps |
| Lens |
3.6 mm |
| Min. Illumination |
Color: 0.02 Lux @(F1.2,AGC on); 0 Lux with IR on |
| Angle of View |
horizontal FOV: 76.9°, vertical FOV: 40.6°, |
| Lens Mount |
M12 |
| Night Vision Distance |
Up to 66ft/20 m |
| DNR |
2D DNR |
| Wide Dynamic Range |
DWDR |
| IR-Cut Filter |
Yes |
| Video Output |
HD BNC X1 |
| Housing |
Plastic |
| Color |
Black |
| Operating Power |
DC 12 V |
| Indoor/Outdoor |
Indoor/Outdoor |
| Weatherproof Rating |
IP67 |
| Dimension (L X W X H) |
5.465 X 2.389 X 2.278"/138.8 X 60.9 X 57.9mm |
| Weight |
0.32 lb./145 g |
Description:
DVR
· Up to 3K high definition live viewing
· Up to 3K Lite recording & playback
· Advanced H. 265 Pro+ Video Compression
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhoneiPadAndroid mobile remote monitoring
· Deep learning based human and vehicle targets classification of Motion Detection 2.0 for all analog channels
· Quick search by object or event type
· Audio via coaxial cable"
Video & Audio:
Video Compression: H. 264+/H. 264/H. 265/H. 265 Pro+
Video Input: 8CH Analog HD/Analog + 2CH IP Video (up to 12 channel when IP enhanced mode on)
Video Output: HDMI and VGA Up to 1080P
Audio Input: 1-ch RCA, 8-ch via coaxial cable
Audio Output: 1-ch RCA
Supported Camera Types: "Support
HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p;
Support AHD Input: 5MP (20FPS) 4MP, 1080p, 720P;
Support CVI Input: 5MP (20FPS), 4MP, 1080p, 720P;
Support CVBS Input;
Support IP Video Input: 6MP/5MP/4MP/3MP/1080P/720P"
Analog HD Playback Resolution: 3K Lite/5MP Lite/4MP Lite@12fps, 1080p/720p@15fps
IPC Playback Resolution: Up to 6MP
Max Playback Channel: 8-ch
Network Protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS
Total Bandwidth: 96Mbps
Remote Connection: 64
Motion Detection 2.0: All analog channels support human and vehicle detection to reduce false alarm
General:
Operating Power: DC12V, 12W (without HDD)
Working Temperature: -14 °F 131 °F /-10 °C 55 °C
Dimensions (W x H x D): 260 × 222 × 45 mm ( 10.2 × 8.7 × 1.8 inch)
Weight (without hard disk): 1 kg ( 2.2 lb) (without HDD)
HD Camera
1080P HD TVI Bullet Security Camera
Up to 20m night vision with Smart EXIR IR
3.6 mm lens brings everything back to life
Clear day and night vision with auto IR-cut
IP67 Dust and Waterproof Rating
Camera:
Image Sensor: 2MP CMOS Image Sensor
Video Resolution: 1920 (H) X 1080 (V)
Signal System: PAL/NTSC
Frame Rate: PAL: 1080p@25 fps NTSC: 1080p@30 fps
Lens: 3.6 mm
Min.
Illumination:
Color: 0.02 Lux @(F 1.2, AGC on); 0 Lux with IR on
Angle of View: horizontal
FOV: 76.9 °, vertical FOV: 40.6 °,
Lens Mount: M12
Night Vision Distance: Up to 66ft/20 m
DNR: 2D DNR
Wide Dynamic RangeL DWDR
IR-Cut Filter: Yes
Video Output: HD BNC X1
General:
Housing: Plastic
Color: White
Operating Power: DC 12 V
Operating Temperature: -40 °F 140 °F/-40 °C 60 °C
Indoor/Outdoor: Indoor/Outdoor
Weatherproof Rating: IP67
Dimension (L X W X H): 5.465 X 2.389 X 2.278" / 138.8 X 60.9 X 57.9 mm
Weight: 0.32 lb. /145 g
