Package
Camera: 1pcs
Adaptor: 1xDC 12V 1A
Camera
Image Sensor: 1/2.9" COMS sensor
Resolution: 2MP 1080P
Effective Pixels: 1920(H)*1080(V)
Compression: H.265
Electronic Shutter Time: Auto(1 / 12s~1 / 100000s)
S/N Ratio: 40dB
Scanning System: Progressive
Video Output: Wireless network
Reset Button: Yes
PTZ
Horizontal Rotation Range: 0~270°
Tilt Rotation Range: 0~90°
Lens Type
Focus Length: 2.8mm F2.0
Focus Control: Fixed
Lens Type: Fixed
Pixels: 2M Pixels
Night Vision
Infrared LED: 14µ x 8PCS
Infrared Distance: 10-15m (Depending On Environment)
IR Status: CDS Auto Control
IR Power: On Auto Control
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: TCP/IP?UDP?HTTP?DDNS?DHCP?FTP?NTP
ONVIF : No
P2P: Support
POE /
Main Stream 1: 1920*1080@25fps
Main Stream 2: /
Main Stream 3: /
Sub Stream 1: 640*480@25fps
Sub Stream 2 /
Sub Stream 3 /
Tri Stream /
IE Brower /
Smart Phone: support
Wireless
Antenna: 3dbi
Hotspot: Support
Wi-Fi: Wi-Fi(IEEE802.11b/g/n)
WIFI Range: No obstacles 350m Max.
Camera Features
Day/Night: Color/ B&W (IR-CUT )
Minimum Illumination: 0.01 Lux
Image Config: YES
Corridor Pattern /
ROI /
Defog Mode /
BLC /
HDR /
3DNR: Support
DWDR: Support
Motion Detection: Support
Privacy Masking /
Recording Mode: SDcard
Language: Chinese, English
Interface
Audio: 2-Way Audio
Alarm: Motion Detection
SD Card Slot: Support Max 128G
General
Housing: plastic, IP65
Bracket: Support
IR Cut Filter: YES
Operation Temperature: -10? ~ +50? RH75% Max
Storage Temperature: -20? ~ +60? RH75% Max
Size: 195(W)x100(H)x190(D)mm
