Camera
Image Sensor: 1/2.8" SONY Low Illumination CMOS Sensor
Horizontal Resolution: 2MP
Compression: H.264/H.264+/H.265/MJPEG
S/N Ratio: >50db
PTZ
Horizontal Rotation Speed: 120°/S
Horizontal Rotation Range: 0°~360°
Tilt Rotation Speed: 30°/S
Tilt Rotation Range: 0°~93°
Preset Points: 220
Guard Tours: 3 groups
Guard Points: Max.16 points
Lens
Focus Length: 5.35mm-96.3mm
Focus Control: 18X Optical Zoom
Night Vision
Infrared LED: 30µx6PCS
IR Range: 60m
Day-night mode: AUTO
Network
Network protocol: TCP/IP,HTTP, NTP,IGMP, DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,PPPoE,P2P
ONVIF: Support
Network interface: Built-in RJ45 network interface,support 10M/100M IP DATA
Main Stream1: 1920*1080@30fps
Main Stream2: 1280*720@30fps
Sub Stream1: 800*448@30fps
Sub Stream2: 704*576@30fps
Sub Stream3: 640*360@30fps
Sub Stream4: 352*288@30fps
AI Function
Smart Analytic: 3D Human Tracking? Intrusion Detection, Line Cross Detection, Alarm Detection
Tracking effective range: 5~45M Speed: 3~12KM/h
Interface
Audio: 2-Way Audio
Alarm /
SD Card Slot /
General
Weatherproof: IP66
Operating Temperature: -40°~ +70°
Operating Humidity: =90% Non Condensing
Power: DC12V/3A / POE
Lightning Protection: Transient voltage 6000V
Dimension: 18.5x 18.5 x 28.8 (cm)
Weight: 2.2Kgs
