Tripp Lite ECO750UPSTAA 750VA 450W UPS Eco Green Battery Back Up 120V USB RJ11 TAA GSA, 12 Outlets

ederal Trade Agreements Act / TAA Compliant for GSA Schedule purchases
750VA ultra-compact 120V standby UPS, energy-saving ECO outlets
Maintains AC output during power failures, 99% line mode efficiency
ECO option turns off set of four outlets when the computer is not in use
USB port, TEL/DSL protection, Wall mountable, Surge-only outlets
NEMA 5-15P input plug and 12 NEMA 5-15R outlets


Ultra-Compact Standby UPS with Energy-Saving Outlets
This energy saving UPS system protects your valuable equipment from damage, downtime and data loss.

Battery backup supports equipment during outages.
Surge protection blocks harmful transient voltages.
The USB interface connects to a computer for power management and automatic file saves.
The ultra-compact, low-profile case saves space.
Energy-saving outlets help prevent idle equipment from wasting electricity.
Energy Star certified efficiency helps you save money, save energy and protect the environment.
The 3-year warranty and insurance reflect Tripp Lite's commitment to product quality and customer satisfaction.
TAA compliance meets the requirements of GSA Schedules and other government contracts.


Key

Specifications

Model: ECO750UPSTAA
Load Capacity: 750 VA (450W)
Nominal AC Input: 120V, 60 Hz
Nominal AC Output: 110V; 115V; 120V, 60 Hz
AC Outlets: 12 x 5-15R (6 UPS, 6 Surge-Only)
Energy-Saving Outlets: 4 of the Surge-Only Outlets
Output Waveform (AC Mode): Sine Wave
Output Waveform (Battery Mode): PWM Sine Wave
Input Cord: 6 ft. ( 1.8 m) Cord with 5-15P Right-Angle Plug
Half-Load Runtime: 9.4 min. (225W Load)
Single-Computer Runtime: 26 min. (100W Load)
Weight: 7.2 lb. ( 3.3 kg)


Power Protection and Battery Backup
Computers and network hardware are under constant attack from power problems. Even a brief loss of power or a momentary surge can damage your equipment, corrupt your data and disrupt your network. This UPS system conditions incoming AC power to protect your equipment, provides enough battery backup to outlast most outages and allows your computer to shut down gracefully during extended blackouts, preventing data loss.

Energy-Saving Outlets
Every AC adapter and glowing LED represents a potential 'phantom load, ' which is electricity wasted by an idle device, even when it appears to be turned off. This UPS system helps eliminate phantom loads by automatically cutting power to special energy-saving outlets when your USB-connected computer shuts down or enters standby mode. Other outlets stay on to support devices that operate continuously, such as wireless routers. When your computer starts up again, the UPS automatically restores power to the energy-saving outlets and your entire system is ready to use.

Common Applications
- Protect Home and Office Computer Systems: Desktop Computers, Workstations, Displays, Inkjet Printers, Modems, Wireless Routers, Hubs, Scanners, External Drives.

- Protect Home and Office Electronics: HDT
Vs, DVRs, Video Game Consoles, Sound Systems, Streaming Media Players, Device/Battery Chargers.

Reliable Battery Backup
- Single-Computer Runtime: This UPS system will support an energy-efficient desktop computer and LCD monitor (100W load) for up to 26 minutes during an outage.

- Half-Load Runtime: This UPS system will support a 50% load (225W) for up to 9.4 minutes.

- Optimized Outlet Array: 6 outlets have both battery backup and surge/noise protection, and 6 have surge/noise protection without battery backup. The 'surge-only' outlets allow you to connect additional equipment without overloading the UPS or reducing the backup runtime. available during an outage.

Protection from Surges, Line Noise and Abnormal Voltages
This UPS system includes built-in surge protection and noise filtering to shield your equipment from destructive transient voltages and electromagnetic (EMI/RFI) line noise. If AC line voltage is too high or too low for your equipment, the UPS system will also provide backup power to the battery-supported outlets until conditions improve or the battery is discharged.

Flexible Management Options
There are two ways to manage this UPS system:


1. Use the HID-compliant USB interface and your computer's built-in power management features.


2. Use the USB interface with Tripp Lite's free PowerAlert software. PowerAlert provides enhanced features like automatic file saves, event notification, logging, advanced device control and an SNMP agent that supports centralized management. You can download the latest version of PowerAlert at Tripp Lite's website.

Data Line Surge Protection
Data and audio/video lines connected to your equipment represent an unlocked 'back door, ' allowing surges to enter and damage or destroy sensitive electronic components. In addition to protecting against surges on the AC power line, this UPS system protects your equipment against surges on a connected phone line.

- The RJ11 jacks protect a phone, analog modem or DSL modem line.

Environmentally Responsible Design
- Energy Star Certification: This UPS system has Energy Star certification. It helps you save money, save energy and protect the environment by meeting strict efficiency guidelines set by the U. S. Environmental Protection Agency.

- Energy-Saving Outlets: This UPS system also has special energy-saving outlets that prevent 'phantom' or 'vampire' loads from wasting electricity when equipment is not being used.

- RoHS Compliance: This UPS system complies with the RoHS (Restriction of Hazardous Substances) Directive, limiting the use of hazardous substances in manufacturing.
