8S 1.2A Inductive Active Equalizer Balancer Energy Transfer Board Li-ion Lipo Lifepo4 LFP Compatible, Lithium Battery Balance, BMS Balancing Protection PCB

Not recommended for use with low strings; the indicator light will flash and report an error. Before connecting the equalization board, be sure to check whether each battery is wired correctly and ensure proper insulation, otherwise it will short-circuit and burn the board.
Applicable battery type: NCM (Li-ion)/LFP, NOT support LTO;
Single voltage working range: 2.0V - 4.5V;
Static working current: 0.01 mA;
Suggested battery capacity: below 30AH. If more than 30AH, please choose high efficiency flying capacitance equalization.
Balance method: Detects when the voltage difference between adjacent batteries is greater than 0.1V to trigger the start of equalization, and when the adjacent battery voltage difference is less than 0.03V to stop working; the board enters under-voltage protection dormant state.
Voltage balance accuracy: 30mV (typical value) between adjacent voltages;
Balance current: 0.1V voltage difference 0.5A - 0.7A balance current, the maximum balance current is 1.2A when the voltage difference is above 0.2V. The smaller the voltage difference between adjacent batteries, the smaller the equalizing current.
Balance indication: 1) When the equalization light is on, the equalization work is turned on; 2) The equalization light goes out, the equalization circuit sleeps; 3) The equalization light flashes, it drops cells, or the circuit is faulty
