QINIYEK is a supplier integrating R&D, production and sales,We specialize in cost-optimized, highly reliable and cost-effective interconnect solutions for the enterprise, access, data center and metro fiber markets, as well as home networks.
We focus on designing Transceiver, DAC&AOC, Converter and Fiber Optical Cable to make the network stable and fast.
![[Pack of 1] 1.25/2.5/5/10G-T SFP+ to RJ45 Transceiver, Copper Ethernet Module, Compatible for Cis...](//c1.neweggimages.com/sellingpilot/modules/product/a-plus/4fca0c83da1cb111f88a1344608c7e6cf4414cb4d9a3c9bf1d17bfbd5d9d0ec5.jpg)
SFP&NIC&Media Converter
Module&DAC&Median Converter
Modules&NIC
![[Pack of 1] 1.25/2.5/5/10G-T SFP+ to RJ45 Transceiver, Copper Ethernet Module, Compatible for Cis...](http://c1.neweggimages.com/sellingpilot/modules/product/a-plus/4fca0c83da1cb111f88a1344608c7e6cf4414cb4d9a3c9bf1d17bfbd5d9d0ec5.jpg)
Comparison Between 10G Transceivers and 1G Transceivers
 10GBase-T |  10GBase-SR |  10GBase-LR |  1000Base-T |  10/100/1000Base-T | |
|---|---|---|---|---|---|
Customer Reviews | — | — | — | — | — |
Price | — | — | — | — | — |
Data Rate | 10G | 10G | 10G | 1000M | 10/100/1000M |
Fiber Type | CAT.6a/CAT.7 | OM3/OM4 | OS2 | CAT.5e | CAT.5e |
Connecter | RJ45 | LC | LC | RJ45 | RJ45 |
Distance | 30m | 300m | 10km | 100m | 100m |
Wavelength(nm) | -- | 850 | 1310 | -- | -- |
Source | -- | VCSEL/PIN | DFB/PIN | -- | -- |
Tx(dBm) | -- | -6.5~-1 | -8.2~-0.5 | -- | -- |
Rx(dBm) | -- | -11.1 | -14.4 | -- | -- |
Temp(?) | 0~70 | 0~70 | 0~70 | 0~70 | 0~70 |
Excellent material & Low Power Chip
Excellent material to ensure the reliability and stability of the product,Low power chip to get a lower power consumption.
Wide Application
Widely applied in fiber Switches&Routers, Network Firwall,Server,Storage,Network Card, or other fiber optic equipments with 10G SFP+ ports, provides additional copper cable connections.
1.25/2.5/5/10G SFP+ to RJ45 Transceiver
Comparison Between 10G Transceivers and 1G Transceivers
10GBase-T | 10GBase-SR | 10GBase-LR | 1000Base-T | 10/100/1000Base-T |
|---|---|---|---|---|
| Customer Reviews | ||||
| — | — | — | — | — |
| Price | ||||
| — | — | — | — | — |
| Data Rate | ||||
| 10G | 10G | 10G | 1000M | 10/100/1000M |
| Fiber Type | ||||
| CAT.6a/CAT.7 | OM3/OM4 | OS2 | CAT.5e | CAT.5e |
| Connecter | ||||
| RJ45 | LC | LC | RJ45 | RJ45 |
| Distance | ||||
| 30m | 300m | 10km | 100m | 100m |
| Wavelength(nm) | ||||
| -- | 850 | 1310 | -- | -- |
| Source | ||||
| -- | VCSEL/PIN | DFB/PIN | -- | -- |
| Tx(dBm) | ||||
| -- | -6.5~-1 | -8.2~-0.5 | -- | -- |
| Rx(dBm) | ||||
| -- | -11.1 | -14.4 | -- | -- |
| Temp(?) | ||||
| 0~70 | 0~70 | 0~70 | 0~70 | 0~70 |
Excellent material & Low Power Chip
Excellent material to ensure the reliability and stability of the product,Low power chip to get a lower power consumption.
Wide Application
Widely applied in fiber Switches&Routers, Network Firwall,Server,Storage,Network Card, or other fiber optic equipments with 10G SFP+ ports, provides additional copper cable connections.
1.25/2.5/5/10G SFP+ to RJ45 Transceiver
| Model | BJ-SFP-10G-T |
|---|---|
| Data Rate: | 1000M,2.5G,5G,10G |
| Reach: | 30m |
| Fiber Type: | Cat6a/Cat7 |
| Temperature: | 0 to 70°C |
| Power Consumption: | =2.5W |
