ENS Titanium IP-5IR8S4C2-MZ 8MP 4K Bullet IP Camera, 2.8-12mm Motorized Zoom, Dual Illumination IR 164ft + White Light 131ft, 120dB WDR, Defog, Human Vehicle Classification, IP67, PoE

Overview

The ENS Titanium IP-5IR8S4C2-MZ is an 8MP (4K) bullet network camera combining a 2.812 mm motorized zoom lens with dual illumination giving you both range and a choice of how to see in the dark. Infrared reaches 3050 m for discreet monochrome monitoring, while white light reaches 3040 m for full-color detail, and smart supplement light selects between them automatically based on conditions. The motorized lens adjusts remotely from a browser or app, scaling the field of view from a wide 97° down to 34° telephoto without a ladder or reopening the housing enough reach to detect activity at 277 m (908 ft) and identify a person at 28 m (91 ft) at full zoom. Image quality is backed by 120 dB HWDR, HLC, BLC, 3D DNR, defog, and image distortion correction. Smart analytics classify targets as human, motor vehicle, or non-motor vehicle to suppress false alarms from animals and weather, with abandoned and missing object detection and SMD. Dual-system backup provides firmware redundancy so a failed update won't brick the camera in the field. Micro SD storage to 256GB with ANR, IP67 weatherproofing, a 30°C to 60°C range, and PoE or 12V DC power under 12W.

Key Features

1. 8MP 4K Resolution 3840 × 2160 detail, with the option to run 6MP, 4MP, or 1080P at a full 30fps when frame rate matters more.
2. 2.812 mm Motorized Zoom Adjust field of view and focus remotely after installation; 97° wide down to 34° telephoto.
3. Dual Illumination Infrared to 3050 m (98164 ft) for covert night monitoring, or white light to 3040 m (98131 ft) for full-color detail.
4. Smart Supplement Light Automatically selects IR or white light based on scene conditions.
5. Long Zoom Reach Detects activity at up to 277 m (908 ft) and identifies at 28 m (91 ft) at full telephoto.
6. 120 dB HWDR Balances harsh backlighting at gates, entrances, and open areas.
7. Defog Improves visibility in fog, haze, and rain not available on most cameras in this class.
8. Smart Classification Line crossing and region intrusion detection distinguishing human, motor vehicle, and non-motor vehicle to cut false alerts.
9. Abandoned & Missing Object Detection Alerts on packages left behind or equipment removed from a scene.
10. Dual-System Backup Firmware redundancy protects against failed updates on remote installs.
11. 256GB Edge Storage with ANR Recording continues through network outages, then backfills automatically.
12. Built-In Microphone Plus a separate 1-channel audio input.
13. Rugged Build IP67 rated, operating from 30°C to 60°C (22°F to 140°F), PoE (802.3af) or 12V DC under 12W.

Specifications

1. Model: IP-5IR8S4C2-MZ | Type: Motorized Zoom Bullet, IP/Network, Dual Illumination
2. Resolution: 8MP (3840 × 2160) | Frame Rate: 120fps at 8MP; up to 30fps at 6MP/4MP/2K/1080P
3. Image Sensor: 1/2.8" CMOS | S/N Ratio: 50 dB
4. Lens: 2.812 mm @ F1.6 motorized zoom, Ø14 mount | DC iris
5. Field of View: 97.3°34° horizontal, 52.3°17.7° vertical, 116°37° diagonal
6. Min. Illumination: 0.02 lux @ F1.6 (AGC on); 0 lux with illumination on
7. Illumination: IR 3050 m (98164 ft) + white light 3040 m (98131 ft), smart supplement light
8. Day/Night: ICR auto switch
9. WDR: 120 dB HWDR | BLC, HLC, 3D DNR, Defog, ROI, image distortion correction, corridor mode
10. Electronic Shutter: 1/3 s to 1/100,000 s
11. Compression: H.265+ / H.265 / H.264+ / H.264 (MJPEG on sub/third streams) | 64 Kbps12 Mbps | VBR/CBR
12. Streams: 3 (main + sub + third)
13. Analytics: Line crossing, region intrusion (human / motor vehicle / non-motor vehicle classification), abandoned & missing object detection, SMD, video exception (scene change, blur, abnormal color)
14. DORI (wide, 2.8mm): Detect 88 m (288 ft) | Observe 35 m (114 ft) | Recognize 17 m (56 ft) | Identify 8 m (27 ft)
15. DORI (tele, 12mm): Detect 277 m (908 ft) | Observe 111 m (364 ft) | Recognize 55 m (180 ft) | Identify 28 m (91 ft)
16. Audio: 1CH input + 1CH built-in microphone | G.711A/U
17. Storage: Micro SD up to 256GB, network remote storage, ANR
18. Network: RJ45 | ONVIF | up to 10 simultaneous users
19. Security: Video/firmware/config encryption, 802.1X, IP filtering, login lock, HTTP/RTSP authentication, watermark, video mask
20. Other: Dual-system backup, cloud upgrade, heartbeat
21. Power: PoE (IEEE 802.3af) or DC 12V | Consumption: <12W
22. Ingress Protection: IP67
23. Operating Conditions: 30°C to 60°C (22°F to 140°F), <95% RH non-condensing
24. Dimensions: 217.8 × 80.5 × 80.3 mm | Weight: approx. 0.68 kg (1.50 lbs)
25. Installation: Ceiling or wall mount | Pan 0360°, Tilt 090°, Rotation 0360°
