XF Robot-Z-1Mini Intelligent 4K Night Vision Micro Pod AI-Powered Multi-Object Tracking & Full-Color Low-Light Imaging

Product Description

XF Robot Z-1Mini AI-Enhanced 4K Full-Color Night Vision Pod with Precision Stabilization

The XF Robot Z-1Mini is an intelligent 4K micro pod designed for low-light imaging, multi-object detection, and real-time tracking. Equipped with an AI-ISP full-color night vision engine, it delivers enhanced visibility in extreme low-light conditions while maintaining sharp details and accurate colors.

Its AI-driven object recognition system detects and tracks persons and vehicles, ensuring precise identification and continuous subject tracking. The integrated 3-axis nonorthogonal mechanical stabilization provides a stabilization accuracy of ±0.01°, enabling smooth and vibration-free performance.

The Z-1Mini is compatible with multiple platforms, featuring network, UART, and S.BUS control options while supporting private protocol and MAVLink. It also enables image transmission via network and HDMI, ensuring seamless real-time monitoring.

Key Features

4K AI-Enhanced Night Vision AI-ISP imaging engine optimizes full-color clarity in extreme low-light conditions.

AI Multi-Object Detection & Tracking Detects persons and vehicles, automatically tracking selected targets with sub-40ms identification delay.

Ultra-Precise 3-Axis Stabilization Dual-IMU stabilization, IMU temperature control, and carrier AHRS fusion ensure ±0.01° stabilization accuracy.

Real-Time Control & Streaming Supports network, UART, and S.BUS control, with image transmission via network and HDMI.

Seamless Software Integration Works with Dragonfly software for real-time image monitoring & control and customized QGC software for full autopilot integration.

OSD & EXIF Data Integration Supports onscreen display (OSD) overlay of latitude, longitude, altitude, and EXIF metadata for shooting coordinates.

Flexible Mounting Options Can be installed in downward or upward orientations for versatile deployment.

High-Performance Storage & Encoding Supports U3/V30 microSD cards up to 256GB, video encoding in H.264 & H.265, and 4K MP4 recording.

Wide Voltage Input Operates on 10V to 26.4V DC, ensuring compatibility across various platforms.

Technical Specifications

Product Name: XF Robot Z-1Mini Intelligent 4K Night Vision Micro Pod

Dimensions: 50.2 x 48.4 x 67.4 mm

Weight: 69g

Operating Voltage: 10V ~ 26.4V DC

Power Consumption: 4.5W (Average) / 18W (Stall)

Mounting Options: Downward / Upward

Gimbal Performance:

Stabilization Type: 3-Axis Nonorthogonal Mechanical Stabilization

Angular Accuracy: ±0.01°

Controllable Range:

Pitch: ±120°

Roll: ±60°

Yaw: ±160°

Maximum Controllable Speed: ±200°/s

Camera Specifications:

Sensor: 1/2.8-inch CMOS, 8.29M Effective Pixels

Lens: 6.0mm Focal Length, f/1.0 Aperture

Field of View (FOV): HFOV: 54.7° VFOV: 30.2° DFOV: 63.2°

Resolution: 3840(H) x 2160(V)

Pixel Size: 1.45m x 1.45m

Digital Zoom: 8x

AI Object Detection & Tracking:

Detection Delay: <40ms

Tracking Speed: ±32 px/field

Refresh Rate: 30Hz

Tracking Deviation Output Delay: 5ms

Image & Video Processing:

Image Format: JPEG

Maximum Image Resolution: 3840 x 2160

EXIF Metadata: Shooting coordinates

Video Format: MP4

Maximum Streaming Resolution: 1920 x 1080 @30fps

Maximum Recording Resolution: 3840 x 2160 @30fps

Encoding Formats: H.264, H.265

Network Protocol: RTSP

Storage:

MicroSD Support: U3/V30 or higher, up to 256GB

Environmental Durability:

Operating Temperature: -20°C ~ 50°C

Storage Temperature: -40°C ~ 60°C

Humidity Resistance: 85% RH (Non-condensing)

Why Choose the XF Robot Z-1Mini?

Designed for high-performance tracking, low-light imaging, and AI-powered surveillance, the Z-1Mini delivers industry-leading stabilization, intelligent object detection, and real-time monitoring. With compact construction, versatile mounting, and seamless software integration, its the ideal choice for professionals seeking precision imaging in dynamic environments.

Unlock next-level imaging and AI tracking with the XF Robot Z-1Mini Order Now!
