XF Robot-Z-2Mini Intelligent 4K Night Vision Dual-Sensor Micro Pod AI-Powered Thermal & Full-Color Imaging with Precision Tracking

Product Description

XF Robot Z-2Mini High-Performance AI-Enhanced Dual-Sensor Night Vision Pod

The XF Robot Z-2Mini is an intelligent dual-sensor micro pod designed for advanced night vision, thermal imaging, and AI-powered object tracking. Equipped with a 4K AI-ISP full-color night vision camera and a long-wave infrared thermal sensor, the Z-2Mini provides detailed visual and thermal imaging for enhanced situational awareness.

With AI-based multi-object detection and tracking, the Z-2Mini intelligently identifies and continuously tracks persons and vehicles, ensuring precise real-time monitoring. The 3-axis nonorthogonal mechanical stabilization, combined with dual-IMU algorithms and temperature-controlled carrier AHRS fusion, delivers ±0.01° stabilization accuracy, guaranteeing smooth, steady imagery in dynamic conditions.

The Z-2Mini supports network, UART, and S.BUS control, along with MAVLink and private protocol compatibility, enabling real-time image transmission via network and HDMI. It seamlessly integrates with Dragonfly software for live monitoring & control, while QGC software enables full autopilot synchronization.

Key Features

Dual-Sensor Imaging 4K AI-ISP full-color night vision camera and infrared thermal sensor provide combined visual & thermal imaging capabilities.

AI Multi-Object Tracking Detects and continuously tracks persons and vehicles with sub-40ms identification delay for precise real-time monitoring.

Precision 3-Axis Stabilization Dual-IMU stabilization, IMU temperature control, and carrier AHRS fusion ensure ±0.01° stabilization accuracy.

High-Resolution Visual Imaging 1/2.8-inch CMOS sensor, 1.45m pixel size, and AI-enhanced night vision for detailed low-light imaging.

Infrared Thermal Imaging Uncooled VOx microbolometer sensor, 12m pixel size, and 8~14m spectral band for clear thermal detection.

Seamless Real-Time Control Supports network, UART, and S.BUS control, with real-time image transmission through network & HDMI.

Software Integration Works with Dragonfly software for real-time image monitoring & QGC for autopilot synchronization.

Advanced OSD & EXIF Metadata Supports onscreen overlay of latitude, longitude, altitude, and EXIF metadata for shooting coordinates.

Compact & Lightweight 110g ultra-light design, adaptable downward or upward mounting.

High-Performance Storage & Video Encoding Supports U3/V30 microSD cards up to 256GB, H.264 & H.265 encoding, 4K MP4 recording, and 1080p streaming.

Wide Voltage Input Operates on 10V to 26.4V DC, ensuring compatibility across multiple platforms.

Technical Specifications

Product Name: AllXF Z-2Mini Intelligent 4K Night Vision Dual-Sensor Micro Pod

Dimensions: 59 x 48.4 x 85.7 mm

Weight: 110g

Operating Voltage: 10V ~ 26.4V DC

Power Consumption: 6.5W (Average) / 20W (Stall)

Mounting Options: Downward / Upward

Gimbal Performance: Stabilization Type: 3-Axis Nonorthogonal Mechanical Stabilization

Angular Accuracy: ±0.01°

Controllable Range:

Pitch: -135° ~ +100°

Roll: ±50°

Yaw: ±150°

Maximum Controllable Speed: ±200°/s

Visual Camera Specifications:

Sensor: 1/2.8-inch CMOS, 8.29M Effective Pixels

Lens: 6.0mm Focal Length, f/1.0 Aperture

Field of View (FOV):

HFOV: 54.7°

VFOV: 30.2°

DFOV: 63.2°

Resolution: 3840(H) x 2160(V)

Pixel Size: 1.45m x 1.45m

Digital Zoom: 8x

Thermal Camera Specifications:

Sensor: Uncooled VOx Microbolometer

Lens: 10.0mm Focal Length, f/1.0 Aperture

Field of View (FOV):

HFOV: 17.5°

VFOV: 13.2°

DFOV: 21.8°

Resolution: 256(H) x 192(V)

Pixel Size: 12m x 12m

Spectral Band: 8~14m

Thermal Sensitivity: <50mk@25

AI Object Detection & Tracking:

Detection Delay: <40ms

Tracking Speed: ±32 px/field

Refresh Rate: 30Hz

Tracking Deviation Output Delay: 5ms

Image & Video Processing:

Image Format: JPEG

Maximum Image Resolution: 3840 x 2160

EXIF Metadata: Shooting coordinates

Video Format: MP4

Maximum Streaming Resolution: 1920 x 1080 @30fps

Maximum Recording Resolution: 3840 x 2160 @30fps

Encoding Formats: H.264, H.265

Network Protocol: RTSP

Storage:

MicroSD Support: U3/V30 or higher, up to 256GB

Environmental Durability:

Operating Temperature: -20°C ~ 50°C

Storage Temperature: -40°C ~ 60°C

Humidity Resistance: 85% RH (Non-condensing)

Why Choose the XF Robot Z-2Mini?

Combining high-resolution full-color imaging, thermal sensing, and AI-powered tracking, the Z-2Mini delivers industry-leading night vision, multi-object detection, and real-time image stabilization. Its compact size, multi-platform adaptability, and cutting-edge AI technology make it the perfect solution for demanding imaging and tracking applications.

Upgrade your imaging system with the XF Robot Z-2Mini Order Now!
