2MP HD 30X Zoom 4-in-1 TVI/CVI/AHD/CVBS Surveillance CCTV Indoor Outdoor Camera

1080P 30X Zoom 2MP AHD/TVI/CVI/CVBS 4 in 1 PTZ IP66 CCTV Security Dome IP Camera

Mini 4in1 PTZ 1080P Security Camera 30x Zoom IR Outdoor Medium Speed Dome 2MP

Model: iBirdView

1. Keep the original analog system
2. Real-time transmission, lossless video
3. High definition 1080P, 30X zoom
4. Long distance transmission up to 500 meters
5. OSD menu available/with 6pcs IR-Led.IR range:80M
6. IR illumination & power consumption is variable dependant on the zoom factor

Parameter:

Camera

Sensor: 1/3'' Sony 323 CMOS

Effective Pixels: 1080P 1920(H) x 1080(V)

Total Pixels: 2.0MP

Lens: 30X f=4.3mm~129mm

Iris: F1.6~F3.0

Min. illumination: Color: 0.5Lux \ B/W: 0.05Lux

BLC: Support

WB: Indoor/outdoor/auto/manual

D/N: IR-Cut

S/N Ratio: 50dB

WDR: DWDR

Dome

DSP: NVP2441

Horizontal Rotation Speed: 0.1°-60°/s

Horizontal Rotation Range: 360°

Tilt Rotation Speed: 0.1°-45°/s

Tilt Rotation Range: 93º

Auto Flip: Horizontal 180°, vertical 93°

Ratio Speed: Support

Preset Points: 220

Go to Preset Speed: 1-9 grades setting available

360° Scan: User programmable

A-B Scan: User programmable

A-B Scan Speed: 1-9 grades setting available

Dwell Preset: 1-60s interval available

Guard Tours: 3 groups

Guard Points: Max.16 points, dwell time user selectable

OSD Menu: Chinese, English

PWR on Action: Memory/Pattern 1/Tour 1/360 scan/AB scan/Preset 1-8/None

Signal Transfer: AHD/CVI/TVI/CVBS selectable

Park Time: 1-60 mins setting available

Pan and Tilt Position Display: Support

Baud Rate: 1200/2400/4800/9600bps

Communication: RS485 /coaxical cable

Operating Temperature: Indoor: 0°~ +40°: Outdoor: -40°~ +60°

Operating Humidity: 95% non condensing

Power Supply: DC12V 3A

Power Consumption: 5W

Lightning Protection: Transient voltage 6000V

IR Parameters

Auto Control IR LED: PWM

LEDs: Array 42Mil

IR Distance: Up to 80 meters

IR illumination On: 1-15 grades selectable

Package Included:

1x 4.5" 4 in 1 Medium Speed Dome Camera

1x Power supply

1x English Manual
