Safe Protection Auto Switch 10A 12V 24V Solar Charger Controller Regulator with LED Indication
- Safe Protection Auto Switch 10A 12V 24V Solar Charger Controller Regulator with LED Indication
+
+
Overview
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Certification:CE
Origin:CN(Origin)
Is Smart Device:NO
is_customized:Yes
Application:Solar System Controller
Maximum Current:10A
This Auto Switch Solar Charger Controller can automatically manage the work of Solar Panel and in solar system. It's widely used for the solar light on street, garden, park, etc. Solar charger controller can control the recharging automatically and make sure the batteries work longer and safer.
Features:
Automatic boost, recovery and float charging capacities for extended life (use temperature compensation)
Over-discharging control voltage modified by the discharging rate curve
Protected against overload, internal and external short circuits, reverse connection, thunder and lightning, and PV panel reverse current
Industry standard production ensures durability and efficiency
Comfortably operate within a wide temperature range
Uses EEP ROM memory to save all work
Control point instead of adjustable resistance to protect the control work point from temperature and vibration fluctuations
PWM high efficiency charging is recommended for optimal operation
There is a button on the controller which can be used to turn on or turn off the load manually
Specifications:
Connection:
Connect the "+", "-" poles of the to the correct ports of controller (the third and the fourth one from left)
If load indicator (mark: load) flickers once and starts lighting after 30 seconds, you can tell the connection is correct and proceed the following operation.
Connect the "+", "-" poles of the solar panel to the correct ports of controller (the first and the second one from left)
Connect the "+", "-" poles of the load to the correct ports of controller (the fifth and the sixth one from left)
The seventh and the eighth "+", "-" poles from left are COM port
Notice:
Please make sure the rated voltage of solar panels, batteries the loads are same and are all 12V or all 24V
The rated current of solar panels and load must be less than the rated current of controller.
