RTL8822CE M.2 WIFI Network Card 867Mbp Wifi Wireless Adapter Card Netowrk Card For E460 E465 E470 E475 E560 E570

Transmission Rate:867Mbps
Certification:NONE
Origin:CN(Origin)
Kind:Internal
Type:wireless
Application:Desktop
Wireless Protocol:802.11n
Length:2X3cm
Adapter Socket:as described
Interface Type:as described
Wi-Fi Supported Frequency:as described
Package:Yes
Model Number:Network Card

Features
This module support MU-MIMO two steams on dual band 2.4GHz or 5GHz operating and incorporates the latest Bluetooth 5.0, the data rate up to 867Mbps on ac mode. The RTL8822CE  is designed by M.2 2230 slot type form factor..
The 802.11ac, Wi-Fi adapter that lets you move at the speed of life with faster speeds (up to 867 Mbps).
The RTL8822CE is using highly integrated single-chip MIMO (Multiple In, Multiple Out) wireless local area network (WLAN) RTL8822CE solution to let users enjoy the high digital content through the latest wireless technology without using cables and cords.
RTL8822CE is an 802.11ac/a/b/g/n Dual -Band WiFi+Bluetooth M.2 (Key A,E) module (WiFi 5) based on Realtek RTL8822CE chipset, It supports Multiple drivers for various platform.
Very easy to install, no extra driver or power require. dramatically reshapes your connected experience at home, work or on the go.
Specifications:
Chipset: Realtek RTL8822CE
Antenna: 2 x IPEX MHF4 Connectors  2T2R
Interface: PCIe: WLAN; USB: Bluetooth
Output Power up to 18dBm
Support: Windows 10, Linux
Size:approx 2X3cm/0.79X1.18in
Package Includes:
1 x Network Card
Note:
Due to the problems of lighting effects and shooting angles, there will be certain tolerances in the product, please understand.
Please allow 0-1cm error due to the manual measurment.
