1730Mbps High Speed 2.4G+5G Dual-Band 802.11ac WiFi Bluetooth 5.0 Module Wireless Card For Intel 9260NGW NGFF Wireless Wifi Card

Transmission Rate:Other
Kind:Internal
Type:wireless
Lan Transmission Rate:1000M Ethernet
Application:Laptop
Certification:CE FC
Wireless Protocol:802.11a/g
Length:Other
Adapter Socket:Other
Interface Type:NGFF
Wi-Fi Supported Frequency:2.4G & 5G
Transmission Speed:1200 Mbps
Package:Yes
Applicable Network Type:Gigabit Ethernet
Model Number:Intel 9260 AC
Condition:Intel 9260ac
Max speed:1.73Gbps
Bands:2.4Ghz / 5Ghz wifi card(160Mhz)
TX/RX Streams:2x2
Weight:M.2 2230:2.9g
Compliance:FIPS,FISMA
Operating Systems:Only work with Windows 10
Integrated Bluetooth:YES
Bluetooth Version:BT 5.0
Stock:100% Intel 9260ac in stock

For Intel® Wireless-AC 9260
The Intel® Wireless-AC 9260 adapter supports Bluetooth® 5 and 2x2 802.11ac Wi-Fi including wave 2 features such as 160MHz channels. delivering up to 1.73Gbps and downlink MU-MIMO.These features deliver a significant increase in user speeds in dense deployments, supporting fast downloads and long life compared to legacy 802.11ac devices. Combined with Intel® Core processors and exceptional Intel wireless innovations, the Intel® Wireless-AC 9260 can provide Gigabit download speed and dramatically improve your connected experience at home, work, or on the go.
Description:
Model:
Intel
9260AC
HP SPS: 920687-001
FRU: 01AX769
Dual band:2.4Ghz / 5Ghz(160Mhz)
Max speed:Speed up to 1730Mbps (The router must on 160Mhz)
Bluetooth Version:Bluetooth 5.0
Interface:NGFF(M.2),22x30mm
Antenna diversity:Supported
Radio ON/OFF control:Supported
Authentication:WPA* and WPA2*,802.11X
Supported Operating Systems:Only work with Microsoft Windows 10
,
Linux*, Google Chrome OS
Note: Not support Windows 7/8/8.1
Compatible With:
It can used on Samsung/Dell/Sony/ACER/ISUS/MSI/Clevo/Terransforce/Hasee etc.
Not support IBM/Thinkpad/lenovo/hp laptop.Only support some Lenovo models.
Package Include:
1 x Intel 9260NGW NGFF Wireless card
Some Screws
