1080P HD Video Converter HDMI-compatible To YPBPR Component R/L Audio Adapter for TV PC Set-Top Box Computer Accessories

Certification:NONE
Origin:CN(Origin)
Resolution:1080P
Type:Adapter/Adapter Cable

HDMI to YPBPR HD video converter
To
working principle:
HDMI to YPbPr HD video converter converts HDMI signals to YPbPr signals and outputs left and right channels at the same time.
product manual:
To
Basic parameters:
Power: 5V1A
Input: HDMI signal, bandwidth 165M, HDMI1.3 compatible
Output: YPBPY signal output with the same resolution as the input HDMI signal, stereo sound signal output
YPBPR signal impedance matching: 75
To
Support HDMI input format is as follows:
480P (60Hz), 576P (50Hz), 720P (50 / 60Hz), 1080i (50 / 60Hz)
Support YPbPr output format is as follows:
480P (60Hz), 576P (50Hz), 720P (50 / 60Hz), 1080i (50 / 60Hz)
product description:
To
This HDMI to YPbPr (color difference) + R / L audio converter converts digital signals to HDMI for YPbPr (Component) analog video and R / L audio
To
signal. It lets users enjoy high-definition images, sound when watching movies or playing traditional VGA monitors or projector games.
To
It provides digital entertainment center, HDTV retail and display space, HDTV, set-top boxes, DVD and projector factories, noise space and security
To
Full questions, data center controls, information distribution, boardroom presentations, solutions for schools and enterprise training environments.
To
Product Features:
To
The series of HDMI converters have many features that make them an excellent way to execute. Among these features, you will find:
1, easy to use: install in a few seconds, no need to set.
2, it can convert the complete HDMI into YPbPr (color difference) video and R / L audio output.
3, support HDCP1.2
4, each channel supports 165MHz /1.65Gbps (6.75Gbps all channels) bandwidth HDMI input.
5, supporting real analog video output up to UXGA and 1080p, 10-bit DAC
6, LED signal and power mode.
7, power supply (5V 1A)
Product acessories:
To
HDMI converter to color converter --------------- 1 Taiwan
To
DC 5V power adapter-1
To
User manual ------------------------ 1 this
To
Product Specifications:
Signal Inputs/Output
Input Video Signal
0.5-1.0 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Input connection
HDMI A female(19pin)
Output connection
VGA, R/L Audio
HDMI video input format
480i/576i/480p/576p/720p/1080i/1080P
YPbPr video output format
480i/576i/480p/576p/720p/1080i/1080P
Audio output format
2 channel LPCM
Operating Frequency
VerticalFrequencyRange
50/60Hz
Input video Amplifier Bandwidth
1.65Gbps/165MHz
Mechanical
Size(LxWxH)
88x68x25.5mm
Weight(Net)
0.68Kg
Warranty
Limited Warranty
1 Year Parts and Labor
Environmentalc
Operating Temperature
0 to +70
Operating Humidity
10% to 85% RH (no condensation)
Storage Temperature
-10 to +80
Storage Humidity
5% to 95% RH (no condensation)
Power Requirement
External Power Supply
DC 5V 1A
Power consumption(Max)
5W
Regulatory Approvals
Converter Unit
CE, FCC, ROHS
Power Supply
CE, FCC, PSE, TK, UL
Accessories Adapter
AC Power Adapter
US standard, UK standard and so on
User Manual
English Version
